Conduit Hole Adaptor

Wisenet P series network vandal outdoor mini Multi-Directional camera 4CH x 4MP @ 15FPS, Fix Lens 3.19mm (FoV H: 97°, V: 54°), triple codec H.265/H.264/MJPEG, 120dB WDR; IR viewable length 20m (65.6ft), USB port for easy installation, Analytics events based on AI engine: Object detection (Person/Vehicle (car/truck/bus/bicycle/bike)), IVA (Virtual line/Area, Enter/Exit, Loitering, direction, intrusion), Appear/Disappear, WiseNR Ⅱ(using AI engine), WiseStreamⅢ(Based on AI engine), I/O Box compatibility; TPM with FIPS 140-2 level2, IP66, IK10, NEMA4X, PoE+, Ø: 200mm, H: 80mm, (HPoE Injector is not included)

The PNO-A7082R is a vandal-resistant 4MP bullet camera with AI and IR. Its 1/1.8-inch CMOS sensor resolves a maximum of 2592x1520 pixels; H.265 and H.264 reach 60fps/50fps (60Hz/50Hz) with WDR off and 30fps/25fps with WDR on, while MJPEG delivers 30fps and no more than 5fps at 4MP. The lens spans 4.6 to 9.35 mm with 2.0x optical zoom, opens to F1.3 wide and F2.15 tele and covers 105° to 47° horizontally and 128° to 55° diagonally. An IR-corrected P iris with simple focus works from a minimum object distance of 1.5 m. Minimum illumination is given as 0.03 lux in colour and 0.003 lux in black and white with automatic ICR switching, and mechanical adjustment allows 0° to 360° pan, 0° to 90° tilt and 0° to 180° rotation. 1/1.8-inch CMOS sensor, 2592x152060fps/50fps WDR off, 30fps/25fps WDR on4.6-9.35 mm lens, 2.0x optical0.03 lux colour / 0.003 lux BWIR-corrected P iris, focus from 1.5 mAutomatic day and night (ICR)

The PNO-A9082R is an 8MP AI bullet camera using a 1/1.2-inch CMOS sensor with a maximum resolution of 3840x2160. H.265 and H.264 streams run at up to 30fps/25fps (60Hz/50Hz), while MJPEG reaches 30fps and is limited to 5fps at 8MP. Sensitivity extends to 0.015 lux in colour and 0.0015 lux in black and white, with automatic ICR day and night switching. The IR corrected P iris lens covers 5.9~13.3mm with 2.25x optical zoom at F1.5 wide and F2.9 tele, giving a horizontal field of view of 109°~49° and a minimum object distance of 0.8m. Installers can align the camera across 0°~360° pan, 0°~90° tilt and 0°~180° rotation, and a USB Type C connection is provided for setup. 1/1.2-inch CMOS sensor, 8MP (3840x2160)5.9~13.3mm lens with 2.25x optical zoomMinimum illumination 0.015 lux colour / 0.0015 lux BWSimple focus with IR corrected P irisPan 0°~360°, tilt 0°~90°, rotate 0°~180°

The PNO-A9092R is a long range 8MP AI bullet camera built on a 1/1.2-inch CMOS sensor with a top resolution of 3840x2160. Its 15~50mm lens provides 3.33x optical zoom at F1.67 wide and F3.5 tele, narrowing the horizontal field of view from 42.7° to 12.6°, with a minimum object distance of 2.5m. H.265 and H.264 encode at up to 30fps/25fps (60Hz/50Hz), and MJPEG runs at 30fps, capped at 5fps when 8MP is selected. Low light performance reaches 0.015 lux in colour and 0.0015 lux in black and white, switched automatically by ICR. Mounting alignment covers 0°~360° pan, 0°~90° tilt and 0°~180° rotation, and the lens uses adaptive P iris with IR correction. 15~50mm long range lens with 3.33x optical zoom1/1.2-inch CMOS sensor, 8MP (3840x2160)Horizontal field of view 42.7°~12.6°Minimum illumination 0.015 lux colour / 0.0015 lux BWMinimum object distance 2.5m

The QNV-C8083R is a vandal resistant dome offering up to 2592x1944 pixels and a motorised varifocal lens from 3.2 to 10.2 mm with 3.2x optical zoom. Aperture ranges from F1.6 at wide to F3.1 at tele, and the field of view spans 95° to 29° horizontally, 69° to 21° vertically and 126° to 36° diagonally, focused by Simple Focus through an IR corrected DC auto iris from 1.2 m. H.265, H.264 and MJPEG are on board, the first two at up to 30 fps at 5 MP and MJPEG at 30 fps, limited to 5 fps at 5 MP. Minimum illumination is stated as 0.07 lux in colour and 0.007 lux in black and white, and IR reaches 30 m. WiseNR II and WiseStream III use the AI engine, joined by 120 dB WDR and ICR switching. The dome bubble is hard coated, with up to five streaming profiles and a Micro SD slot for 256 GB. Motorised varifocal 3.2 to 10.2 mm, 3.2xF1.6 wide, F3.1 tele, Simple FocusIR viewable length 30 m0.07 lux colour, 0.007 lux black and white120 dB WDR, WiseNR II, WiseStream IIIMicro SD/SDHC/SDXC up to 256 GB

The QNV-C9083R records at 3840x2160 pixels and combines its 1/2.8 inch CMOS sensor with a motorised varifocal lens from 3.2 to 10.2 mm at 3.2x optical zoom. Aperture sits between F1.6 at wide and F3.1 at tele, while the angle of view moves from 104° to 31° horizontally, 55° to 17° vertically and 124° to 35° diagonally. Simple Focus and the IR corrected DC auto iris operate from a minimum object distance of 1.2 m. H.265 and H.264 manage 30 fps on 60 Hz or 25 fps on 50 Hz, MJPEG reaches 30 fps and 5 fps at 8 MP, and up to five streaming profiles can run in parallel. Low light performance is quoted at 0.06 lux in colour and 0.006 lux in black and white, with 120 dB WDR and ICR switching alongside. Footage is stored on a Micro SD/SDHC/SDXC card of up to 256 GB. 3840x2160 pixels, up to 30/25 fpsMotorised varifocal 3.2 to 10.2 mm, 3.2xF1.6 wide, F3.1 tele, Simple Focus0.06 lux colour, 0.006 lux black and white120 dB WDR, ICR day and night switchingMicro SD/SDHC/SDXC up to 256 GB

The SPS-A100M is an audio beacon fitted with five built-in MEMS microphones and a speaker rated at a maximum sound pressure level of 90dB at 1m(3.28ft) across a frequency range of 144Hz~20kHz. Audio streaming is selectable between two-way and one-way, runs full duplex and applies echo cancellation and noise reduction. AI-based sound classification distinguishes crashing glass, screaming, vehicle horn and tire screech, returning metadata for sound type, sound direction, confidence, timestamp, best sound audio file and dB(±10dB); ceiling mounting resolves direction to ±15 degrees. Alarm triggers include analytics, network disconnect, alarm input, app event, time schedule and MQTT subscription, and a triggered event can upload audio by e-mail or FTP, send an e-mail notification, drive the alarm output or hand over to a PTZ preset. Two configurable I/O ports, an LED ring in green, blue, red, pink, sky blue and purple for event actions and RJ-45(10/100 BASE-T) with unicast for up to six users complete the device. Full-duplex two-way audio, one-way selectableFive built-in MEMS microphonesSpeaker with max. 90dB at 1m(3.28ft)AI-based sound classification with event metadataSound direction ±15 degrees at ceiling mountingSix-colour LED ring for event action

The TNO-C3040T is a thermal camera with a tele lens and AI capability. Its uncooled micro bolometer carries 384x288 pixels at a 17 µm pitch and works in the 8~14 µm band, with thermal sensitivity quoted as ≤20 mK at 25 °C and F1.0. Images are output at 768x576 and 384x288 with up to 30 frames per second in H.265, H.264 and MJPEG, and a micro USB type B connector serves preview and installation. In front of the sensor sits an athermalised 13 mm fixed lens at F1.0 covering 28.5° horizontally, 21.4° vertically and 35.5° diagonally, for an iFoV of 1.308 mRad and a minimum object distance of 5 m. During installation the camera can be panned 0°~350°, tilted 0°~90° and rotated 0°~350°, and eight 8-point polygonal motion detection zones are available for analysis. Uncooled micro bolometer, 384x288, 17 µmNETD ≤20 mK at 25 °C, F1.0Athermalised 13 mm fixed lens, F1.0Field of view 28.5° x 21.4°, iFoV 1.308 mRadUp to 30 fps in H.265, H.264 and MJPEGEight 8-point polygonal motion detection zones

The TNO-C3042T pairs an athermalised 13 mm tele lens at F1.0 with an uncooled micro bolometer of 384x288 pixels and a 17 µm pixel pitch, reaching a thermal sensitivity of ≤20 mK at 25 °C and F1.0 within the 8~14 µm band. Output resolutions are 768x576 and 384x288 at up to 8 frames per second in H.265, H.264 and MJPEG. The field of view measures 28.5° horizontally, 21.4° vertically and 35.5° diagonally, with an iFoV of 1.308 mRad and a minimum object distance of 5 m. Detected objects are classified as person or vehicle by an AI engine. The housing is rated IP66/67, IK10, NEMA4X, NEMA-TS2 and MIL-STD-810H, and a secure element certified to FIPS 140-3 level 3 and CC EAL6+ protects the camera. Uncooled micro bolometer, 384x288, 17 µmNETD ≤20 mK at 25 °C, F1.0Athermalised 13 mm tele lens, F1.0Max. 8 fps in H.265, H.264 and MJPEGAI classification of person and vehicleIP66/67, IK10, NEMA4X, NEMA-TS2, MIL-STD-810H

The TNO-C3052T images through an uncooled micro bolometer of 384x288 with a pixel size of 17 µm and streams either 768x576 or 384x288. Its spectral range covers 8–14 µm, and sensitivity is stated as NETD ≤20 mK at 25 °C, F1.0. The athermalized fixed lens has a focal length of 19 mm at F1.0 and takes in 19.3° horizontally, 14.6° vertically and 23.9° diagonally, with an iFoV of 0.895 mRad and a minimum object distance of 10.6 m (34.8 ft). H.265, H.264 and MJPEG are each encoded at up to 8 fps, and AI-based classification separates persons from vehicles. Eight motion zones can be drawn as 8-point polygons, and the mount permits 0°~350° of pan, 0°~90° of tilt and 0°~350° of rotation. Uncooled micro bolometer 384x288Athermalized 19 mm fixed lens, F1.0NETD ≤20 mK at 25 °CUp to 8 fps (H.265/H.264/MJPEG)AI object classification for persons and vehiclesIP66/67, IK10, NEMA4X, NEMA-TS2, MIL-STD-810H

The TNO-C3060T images through an uncooled micro bolometer of 384x288 with a pixel size of 17 µm and streams either 768x576 or 384x288. Its spectral range covers 8–14 µm, and sensitivity is stated as NETD ≤20 mK at 25 °C, F1.0. The athermalized fixed lens has a focal length of 35 mm at F1.0 and takes in 10.7° horizontally, 8.0° vertically and 13.3° diagonally, with an iFoV of 0.486 mRad and a minimum object distance of 36.1 m (118.4 ft). H.265, H.264 and MJPEG are each encoded at up to 30 fps, and AI-based classification separates persons from vehicles. Eight motion zones can be drawn as 8-point polygons, and the mount permits 0°~350° of pan, 0°~90° of tilt and 0°~350° of rotation. Uncooled micro bolometer 384x288Athermalized 35 mm fixed lens, F1.0NETD ≤20 mK at 25 °CUp to 30 fps (H.265/H.264/MJPEG)AI object classification for persons and vehiclesIP66/67, IK10, NEMA4X, NEMA-TS2, MIL-STD-810H

The TNO-C3062T images through an uncooled micro bolometer of 384x288 with a pixel size of 17 µm and streams either 768x576 or 384x288. Its spectral range covers 8–14 µm, and sensitivity is stated as NETD ≤20 mK at 25 °C, F1.0. The athermalized fixed lens has a focal length of 35 mm at F1.0 and takes in 10.7° horizontally, 8.0° vertically and 13.3° diagonally, with an iFoV of 0.486 mRad and a minimum object distance of 36.1 m (118.4 ft). H.265, H.264 and MJPEG are each encoded at up to 8 fps, and AI-based classification separates persons from vehicles. Eight motion zones can be drawn as 8-point polygons, and the mount permits 0°~350° of pan, 0°~90° of tilt and 0°~350° of rotation. Uncooled micro bolometer 384x288Athermalized 35 mm fixed lens, F1.0NETD ≤20 mK at 25 °CUp to 8 fps (H.265/H.264/MJPEG)AI object classification for persons and vehiclesIP66/67, IK10, NEMA4X, NEMA-TS2, MIL-STD-810H

The TNO-C3080T images through an uncooled micro bolometer of 384x288 with a pixel size of 17 µm and streams either 768x576 or 384x288. Its spectral range covers 8–14 µm, and sensitivity is stated as NETD ≤20 mK at 25 °C, F1.0. The athermalized fixed lens has a focal length of 60 mm at F1.2 and takes in 6.2° horizontally, 4.7° vertically and 7.7° diagonally, with an iFoV of 0.283 mRad and a minimum object distance of 88.3 m (289.7 ft). H.265, H.264 and MJPEG are each encoded at up to 30 fps, and AI-based classification separates persons from vehicles. Eight motion zones can be drawn as 8-point polygons, and the mount permits 0°~350° of pan, 0°~90° of tilt and 0°~350° of rotation. Uncooled micro bolometer 384x288Athermalized 60 mm fixed lens, F1.2NETD ≤20 mK at 25 °CUp to 30 fps (H.265/H.264/MJPEG)AI object classification for persons and vehiclesIP66/67, IK10, NEMA4X, NEMA-TS2, MIL-STD-810H

The TNO-C3082T images through an uncooled micro bolometer of 384x288 with a pixel size of 17 µm and streams either 768x576 or 384x288. Its spectral range covers 8–14 µm, and sensitivity is stated as NETD ≤20 mK at 25 °C, F1.0. The athermalized fixed lens has a focal length of 60 mm at F1.2 and takes in 6.2° horizontally, 4.7° vertically and 7.7° diagonally, with an iFoV of 0.283 mRad and a minimum object distance of 88.3 m (289.7 ft). H.265, H.264 and MJPEG are each encoded at up to 8 fps. Eight motion zones can be drawn as 8-point polygons, and the mount permits 0°~350° of pan, 0°~90° of tilt and 0°~350° of rotation. Uncooled micro bolometer 384x288Athermalized 60 mm fixed lens, F1.2NETD ≤20 mK at 25 °CUp to 8 fps (H.265/H.264/MJPEG)Field of view 6.2° x 4.7°Minimum object distance 88.3 m (289.7 ft)

The XNO-A6084R is a bullet camera on a 1/2.8" CMOS imager, recording at up to 1920x1080 with smaller formats down to 320x180. H.265 and H.264 run at 60fps/50fps (60Hz/50Hz) and MJPEG at 30fps. Its motorised lens covers 2.8~12 mm with 4.3x optical zoom, apertures from 1.4 wide to 3.6 tele and a field of view of 120°~27° horizontally, 63°~15° vertically and 143°~32° diagonally, focused by simple focus or manually from 0.5 m. Built as a P iris lens with IR correction, the camera reaches 0.02 lux in colour and 0.002 lux in black and white (1/30 sec, 30 IRE) with automatic ICR day and night switching. Alignment ranges are 0°~350° pan, 0°~90° tilt and 0°~350° rotate, and the video output is a USB Type C connector. Up to 1920x1080, 60fps2.8~12 mm, 4.3x optical zoomP iris lens, IR corrected0.02 lux colour / 0.002 lux B/WAuto ICR day and night0°~350° pan, 0°~90° tilt, 0°~350° rotate

As a bullet camera with a 1/2.8" CMOS imager, the XNO-A8084R resolves up to 2560x1920. H.265 and H.264 are encoded at 30fps/25fps (60Hz/50Hz) and MJPEG at 30fps, though at 5MP it is limited to 5fps. The motorised lens operates from 3.3~9.3 mm with 2.8x optical zoom at apertures of 1.3 wide and 2.3 tele, giving 99°~31° horizontally, 71°~23° vertically and 133°~39° diagonally from 0.5 m. It is a P iris design with IR correction, adjusted by simple focus or manually. Sensitivity is quoted as 0.04 lux in colour and 0.004 lux in black and white (1/30 sec, 30 IRE) with automatic ICR day and night switching. Ranges of 0°~350° pan, 0°~90° tilt and 0°~350° rotate ease alignment, and a USB Type C connector serves as video output. Up to 2560x19203.3~9.3 mm, 2.8x optical zoomP iris, IR corrected0.04 lux colour / 0.004 lux B/WAuto ICR day and night0°~350° pan, 0°~90° tilt, 0°~350° rotate

The XNO-A9084R uses a 1/1.8" CMOS imager and records at up to 3840x2160, with H.265 and H.264 reaching 30fps/25fps (60Hz/50Hz) and MJPEG 30fps, limited to 5fps at 8MP. Its motorised lens spans 4.4~9.3 mm with 2.1x optical zoom, at aperture ratios of 1.3 wide and 2.15 tele. Coverage is 113°~47° horizontally, 58°~26° vertically and 138°~54° diagonally from a minimum object distance of 0.5 m, set through simple focus or manually. The P iris lens is IR corrected, minimum illumination is 0.04 lux in colour and 0.004 lux in black and white (1/30 sec, 30 IRE), and ICR switches between day and night automatically. Installation is supported by 0°~350° pan, 0°~90° tilt and 0°~350° rotate, and video output is over a USB Type C connector. 1/1.8" CMOS sensorUp to 3840x21604.4~9.3 mm, 2.1x optical zoomP iris, IR corrected0.04 lux colour / 0.004 lux B/W0°~350° pan, 0°~90° tilt, 0°~350° rotate

This AI bullet camera works with a 1/2.8 inch CMOS sensor, resolves up to 1920x1080 and reaches 60fps/50fps (60Hz/50Hz) in H.265 and H.264, while MJPEG runs at 30fps. Its motorised varifocal lens covers 2.8 to 12 mm with 4.3x optical zoom, an aperture of F1.4 at the wide end and F3.6 at tele, and a horizontal field of view between 120 and 27 degrees. Minimum illumination is 0.01 lux in colour and 0.001 lux in black and white at 1/30 sec and 30 IRE, with WiseIR illumination reaching 40 m (131.23ft). Day and night switching is handled automatically by ICR, extremeWDR spans 150 dB, and digital image stabilisation relies on a built-in gyro sensor. Streaming uses H.265, H.264 and MJPEG together with WiseStream II and WiseStream III, and focus can be set by simple focus or manually. 1/2.8 inch CMOS, up to 1920x10802.8~12 mm varifocal, 4.3x optical zoom60fps/50fps in H.265/H.264WiseIR range 40 m (131.23ft)extremeWDR 150 dB, ICR day and nightDIS with built-in gyro sensor

A 1/2.8 inch CMOS sensor gives this 4MP IR bullet camera a maximum resolution of 2592x1520. H.265 and H.264 run at 60fps/50fps (60Hz/50Hz) with WDR off and 30fps/25fps with WDR on, while MJPEG delivers 30fps and a maximum of 5fps at 4MP. The motorised varifocal lens spans 2.8 to 10 mm with 3.6x optical zoom, F1.4 wide and F3.0 tele, covering 110 to 30 degrees horizontally and 61 to 17 degrees vertically. Stated minimum illumination is 0.038 lux in colour and 0.0038 lux in black and white, WiseIR reaches 40 m (131.23ft), and extremeWDR operates at 120 dB. The NPU-based AI engine detects persons, faces, vehicles (car, truck, bus, bicycle, motorcycle) and licence plates, and supplies IVA events such as virtual line or area, enter and exit, loitering, direction and intrusion. 1/2.8 inch CMOS, up to 2592x15202.8~10 mm varifocal, 3.6x optical zoom0.038 lux colour / 0.0038 lux BWWiseIR range 40 m (131.23ft)extremeWDR 120 dB, ICR day and nightAI engine (NPU) object detection and IVA

This 6MP bullet camera uses a larger 1/1.8 inch CMOS sensor and reaches a maximum resolution of 3328x1872. H.265 and H.264 encode at 30fps/25fps (60Hz/50Hz), while MJPEG runs at 30fps and drops to a maximum of 5fps at 6MP. Its motorised varifocal lens covers 4.4 to 9.3 mm, equal to 2.1x optical zoom, opens to F1.3 wide and F2.15 tele and spans 113 to 47 degrees horizontally, 58 to 26 degrees vertically and 138 to 54 degrees diagonally. Minimum illumination is 0.04 lux in colour and 0.004 lux in black and white, WiseIR illuminates up to 40 m (131.23ft), and extremeWDR works at 120 dB. Noise reduction is handled by WiseNR II using the AI engine, complemented by WiseStream II and WiseStream III, DIS with a built-in gyro sensor and an IR-corrected P iris lens. 1/1.8 inch CMOS, up to 3328x18724.4~9.3 mm varifocal, 2.1x optical zoom30fps/25fps in H.265/H.264WiseIR range 40 m (131.23ft)extremeWDR 120 dB, WiseNR IIIR-corrected P iris lens

The 4K member of this bullet range records up to 3840x2160 from a 1/1.8 inch CMOS sensor. H.265 and H.264 operate at 30fps/25fps (60Hz/50Hz), and MJPEG reaches 30fps with a maximum of 5fps at 8MP. The motorised varifocal lens runs from 4.4 to 9.3 mm (2.1x), opens to F1.3 wide and F2.15 tele and captures 113 to 47 degrees horizontally and 138 to 54 degrees diagonally. For low light the manufacturer states 0.04 lux in colour and 0.004 lux in black and white, 0 lux with the IR LEDs switched on, and a WiseIR range of 40 m (131.23ft). Also included are extremeWDR at 120 dB, WiseNR II and WiseStream III driven by the AI engine, plus DIS with a built-in gyro sensor. 1/1.8 inch CMOS, up to 3840x21604.4~9.3 mm varifocal, 2.1x optical zoom0.04 lux colour / 0.004 lux BWWiseIR range 40 m (131.23ft)extremeWDR 120 dB, WiseNR IIDIS with built-in gyro sensor
