Wall&Pole Mount

The TNO-4050T resolves thermal scenes at 640x480, with 640x360 and 320x240 available as alternatives. Its uncooled micro bolometer uses a 17 µm pixel pitch, a thermal sensitivity of ≤50 mK and the 8~14 µm spectral band, and frame rates reach 30/25 fps (60/50 Hz) in H.265 and H.264 as well as 30 fps in MJPEG. A fixed 35 mm F1.0 lens sits in front of the sensor and covers 17.2° horizontally, 13° vertically and 22° diagonally, for an iFoV of 0.47 mRad and a minimum object distance of 36 m. Analytics include motion detection with handover, tampering and loitering detection, directional detection, audio detection, sound classification, and detection of shock and temperature change. An SD/SDHC/SDXC slot takes up to 256 GB of recordings, and Hallway View and WiseStream II are supported. Uncooled micro bolometer, 640x480, 17 µmNETD ≤50 mK, 8~14 µm spectral range35 mm fixed lens, F1.0, field of view 17.2° x 13°Up to 30/25 fps in H.265 and H.264Shock and temperature change detectionSD/SDHC/SDXC up to 256 GB

A 640x480 uncooled micro bolometer with a 17 µm pixel size drives the TNO-C4040T, which outputs 1280x960, 640x480, 640x360 or 320x240. Across the 8–14 µm spectral range, sensitivity is specified as NETD ≤16 mK at 25 °C, F1.0. The athermalized 13 mm fixed lens at F1.0 spans 49.1° horizontally and 36.4° vertically, 62.3° on the diagonal, with an iFoV of 1.31 mRad and a minimum object distance of 5 m (16.4 ft). H.265 and H.264 reach 30fps/25fps (60Hz/50Hz) and MJPEG 30fps. WiseNR digital noise reduction conditions the image, and eight zones are available for motion detection. An SD/SDHC/SDXC slot takes cards of up to 256 GB, Hallway View and WiseStream II are supported, power comes from PoE, 24 V AC or 12 V DC, and the housing is rated IP66, NEMA4X and IK10. Uncooled micro bolometer 640x480Athermalized 13 mm fixed lens, F1.0NETD ≤16 mK at 25 °CUp to 30fps/25fps (60Hz/50Hz) (H.265/H.264)SD/SDHC/SDXC slot up to 256 GBIP66, NEMA4X, IK10

A 640x480 uncooled micro bolometer with a 17 µm pixel size drives the TNO-C4042T, which outputs 1280x960, 640x480, 640x360 or 320x240. Across the 8–14 µm spectral range, sensitivity is specified as NETD ≤16 mK at 25 °C, F1.0. The athermalized 13 mm fixed lens at F1.0 spans 49.1° horizontally and 36.4° vertically, 62.3° on the diagonal, with an iFoV of 1.31 mRad and a minimum object distance of 5 m (16.4 ft). H.265 and H.264 reach 8fps and MJPEG 8fps. WiseNR digital noise reduction conditions the image, and eight zones are available for motion detection. Persons, vehicles and vessels are detected, and the image can be upscaled to 1280x960. Uncooled micro bolometer 640x480Athermalized 13 mm fixed lens, F1.0NETD ≤16 mK at 25 °CUp to 8fps (H.265/H.264)Person, vehicle and vessel detectionMIL-STD, NEMA 4X, NEMA TS rated

A 640x480 uncooled micro bolometer with a 17 µm pixel size drives the TNO-C4050T, which outputs 1280x960, 640x480, 640x360 or 320x240. Across the 8–14 µm spectral range, sensitivity is specified as NETD ≤16 mK at 25 °C, F1.0. The athermalized 19 mm fixed lens at F1.0 spans 32.8° horizontally and 24.6° vertically, 41.1° on the diagonal, with an iFoV of 0.89 mRad and a minimum object distance of 11 m (36.1 ft). H.265 and H.264 reach 30fps/25fps (60Hz/50Hz) and MJPEG 30fps. WiseNR digital noise reduction conditions the image, and eight zones are available for motion detection. The image can be upscaled to 1280x960, and the camera carries MIL-STD, NEMA 4X and NEMA TS ratings. Uncooled micro bolometer 640x480Athermalized 19 mm fixed lens, F1.0NETD ≤16 mK at 25 °CUp to 30fps/25fps (60Hz/50Hz) (H.265/H.264)Upscaling to 1280x960MIL-STD, NEMA 4X, NEMA TS rated

A 640x480 uncooled micro bolometer with a 17 µm pixel size drives the TNO-C4052T, which outputs 1280x960, 640x480, 640x360 or 320x240. Across the 8–14 µm spectral range, sensitivity is specified as NETD ≤16 mK at 25 °C, F1.0. The athermalized 19 mm fixed lens at F1.0 spans 32.8° horizontally and 24.6° vertically, 41.1° on the diagonal, with an iFoV of 0.89 mRad and a minimum object distance of 11 m (36.1 ft). H.265 and H.264 reach 8fps and MJPEG 8fps. WiseNR digital noise reduction conditions the image, and eight zones are available for motion detection. Persons, vehicles and vessels are detected, and the image can be upscaled to 1280x960. Uncooled micro bolometer 640x480Athermalized 19 mm fixed lens, F1.0NETD ≤16 mK at 25 °CUp to 8fps (H.265/H.264)Person, vehicle and vessel detectionMIL-STD, NEMA 4X, NEMA TS rated

A 640x480 uncooled micro bolometer with a 17 µm pixel size drives the TNO-C4060T, which outputs 1280x960, 640x480, 640x360 or 320x240. Across the 8–14 µm spectral range, sensitivity is specified as NETD ≤16 mK at 25 °C, F1.0. The athermalized 35 mm fixed lens at F1.0 spans 17.5° horizontally and 13.2° vertically, 21.7° on the diagonal, with an iFoV of 0.47 mRad and a minimum object distance of 36 m (118.1 ft). H.265 and H.264 reach 30fps/25fps (60Hz/50Hz) and MJPEG 30fps. WiseNR digital noise reduction conditions the image, and eight zones are available for motion detection. The image can be upscaled to 1280x960, and the camera carries MIL-STD, NEMA 4X and NEMA TS ratings. Uncooled micro bolometer 640x480Athermalized 35 mm fixed lens, F1.0NETD ≤16 mK at 25 °CUp to 30fps/25fps (60Hz/50Hz) (H.265/H.264)Upscaling to 1280x960MIL-STD, NEMA 4X, NEMA TS rated

A 640x480 uncooled micro bolometer with a 17 µm pixel size drives the TNO-C4062T, which outputs 1280x960, 640x480, 640x360 or 320x240. Across the 8–14 µm spectral range, sensitivity is specified as NETD ≤16 mK at 25 °C, F1.0. The athermalized 35 mm fixed lens at F1.0 spans 17.5° horizontally and 13.2° vertically, 21.7° on the diagonal, with an iFoV of 0.47 mRad and a minimum object distance of 36 m (118.1 ft). H.265 and H.264 reach 8fps and MJPEG 8fps. WiseNR digital noise reduction conditions the image, and eight zones are available for motion detection. Persons, vehicles and vessels are detected, and the image can be upscaled to 1280x960. Uncooled micro bolometer 640x480Athermalized 35 mm fixed lens, F1.0NETD ≤16 mK at 25 °CUp to 8fps (H.265/H.264)Person, vehicle and vessel detectionMIL-STD, NEMA 4X, NEMA TS rated

A 640x480 uncooled micro bolometer with a 17 µm pixel size drives the TNO-C4080T, which outputs 1280x960, 640x480, 640x360 or 320x240. Across the 8–14 µm spectral range, sensitivity is specified as NETD ≤16 mK at 25 °C, F1.0. The athermalized 60 mm fixed lens at F1.15 spans 10.3° horizontally and 7.7° vertically, 12.8° on the diagonal, with an iFoV of 0.28 mRad and a minimum object distance of 92 m (301.8 ft). H.265 and H.264 reach 30fps/25fps (60Hz/50Hz) and MJPEG 30fps. WiseNR digital noise reduction conditions the image, and eight zones are available for motion detection. The image can be upscaled to 1280x960, and the camera carries MIL-STD, NEMA 4X and NEMA TS ratings. Uncooled micro bolometer 640x480Athermalized 60 mm fixed lens, F1.15NETD ≤16 mK at 25 °CUp to 30fps/25fps (60Hz/50Hz) (H.265/H.264)Upscaling to 1280x960MIL-STD, NEMA 4X, NEMA TS rated

A 640x480 uncooled micro bolometer with a 17 µm pixel size drives the TNO-C4082T, which outputs 1280x960, 640x480, 640x360 or 320x240. Across the 8–14 µm spectral range, sensitivity is specified as NETD ≤16 mK at 25 °C, F1.0. The athermalized 60 mm fixed lens at F1.15 spans 10.3° horizontally and 7.7° vertically, 12.8° on the diagonal, with an iFoV of 0.28 mRad and a minimum object distance of 92 m (301.8 ft). H.265 and H.264 reach 8fps and MJPEG 8fps. WiseNR digital noise reduction conditions the image, and eight zones are available for motion detection. Persons, vehicles and vessels are detected, and the image can be upscaled to 1280x960. Uncooled micro bolometer 640x480Athermalized 60 mm fixed lens, F1.15NETD ≤16 mK at 25 °CUp to 8fps (H.265/H.264)Person, vehicle and vessel detectionMIL-STD, NEMA 4X, NEMA TS rated

The XND-A8085RV is a modular 5MP AI IR dome camera built on a 1/2.8" CMOS sensor with a top resolution of 2560x1920. A motorised 3.3 to 9.3 mm varifocal lens with 2.8x zoom and an IR-corrected P iris works at F1.3 wide and F2.3 tele, covering 99° to 31° horizontally, 71° to 23° vertically and 133° to 39° diagonally from a 0.5 m minimum object distance. Frame rates are 30fps/25fps (60Hz/50Hz) in H.265 and H.264, with MJPEG at 30fps and a maximum of 5fps at 5MP. Minimum illumination is stated as 0.04 lux in colour and 0.004 lux in black-and-white, and an ICR handles day and night switching automatically. A tilt range of -45° to 85° together with 0° to 360° pan and 0° to 355° rotation allows flexible alignment, and focusing is by simple focus. Modular design, 5MPMotorised 3.3–9.3 mm varifocal lens, 2.8xIR-corrected P iris, F1.3 to F2.3Tilt range -45° to 85°0.04 lux colour, 0.004 lux B/WICR day and night switching

In a modular design, the XND-A9085RV is an 8MP AI IR dome camera delivering up to 3840x2160 from a 1/1.8" CMOS sensor. Its motorised 4.4 to 9.3 mm varifocal lens works with 2.1x zoom, an IR-corrected P iris, F1.3 wide and F2.15 tele, covering 113° to 47° horizontally, 58° to 26° vertically and 138° to 54° diagonally, with a minimum object distance of 0.5 m. H.265 and H.264 run at 30fps/25fps (60Hz/50Hz) and MJPEG at 30fps, limited to 5fps at 8MP. Minimum illumination is given as 0.04 lux in colour and 0.004 lux in black-and-white, and an ICR performs day and night switching. Tilt ranges from -45° to 85°, complemented by 0° to 360° pan and 0° to 355° rotation, and focusing is by simple focus. Modular design, 8MP1/1.8" CMOS, up to 3840x2160Motorised 4.4–9.3 mm varifocal lens, 2.1xIR-corrected P iris, F1.3 to F2.15Tilt range -45° to 85°0.04 lux colour, 0.004 lux B/W

The XNV-A8016R is a compact outdoor IR network dome camera with a 1/2.8" CMOS sensor and a maximum resolution of 2560 x 1920 pixels (5 MP). Its 3.0 mm fixed-iris lens at F1.6 is focused manually and covers 100° horizontally, 74° vertically and 130° diagonally from 0.4 m. H.265 and H.264 operate at up to 30 fps or 25 fps and MJPEG at 30 fps, limited to 5 fps at 5 MP, while minimum illumination is given as 0.06 lux in colour and 0.006 lux in black and white. Automatic ICR day and night switching plus BLC, HLC, WDR and SSDR support changing light conditions. The USB Type-C port is for preview and installation only and requires a WiFi dongle, and alignment offers 0°~351° pan, 0°~64° tilt and ±90° rotation. 5 MP resolution (2560 x 1920)3.0 mm lens with fixed F1.6 iris100° horizontal field of viewDay and night (ICR), BLC, HLC, WDR, SSDR0.06 lux colour, 0.006 lux black and whiteAdjustment range 0°~351°, 0°~64°, ±90°

The XNV-A9016R is a compact outdoor 4K network dome camera with 25m of infrared reach in a housing measuring 120mm in diameter and 65.5mm in height. Its 1/2.8-inch CMOS sensor provides 8MP at up to 3840x2160 pixels; H.265 and H.264 deliver 30fps at 60Hz or 25fps at 50Hz, and MJPEG runs at 30fps, limited to 5fps at 8MP. A fixed 3.0mm lens with fixed iris and manual focus control covers 108 degrees horizontally, 59 degrees vertically and 127 degrees diagonally, focusing from 0.4m. Minimum illumination is given as 0.1 lux in colour and 0.01 lux in black and white, and backlight situations are addressed by BLC, HLC, WDR and SSDR. Processing runs on Wisenet 9 with a dual NPU that separates AI processing from image enhancement, which is what the analytics events and business intelligence functions build on. The housing is rated IP66 and IK10, and alignment uses 0 to 351 degrees of pan, 0 to 64 degrees of tilt and plus/minus 90 degrees of rotation. 8MP, up to 3840x2160 pixelsFixed 3.0mm focal length, fixed iris25m IR rangeIP66, IK10 ratedWisenet 9 with dual NPUBLC, HLC, WDR, SSDR
