Vandal Dome Backbox

The XNV-6083RZ is a vandal-resistant AI IR dome camera capturing up to 1920 x 1080 pixels (2 MP) on a 1/2.8" CMOS sensor. Its motorised varifocal lens runs from 2.8 to 12 mm with 4.3x optical zoom, F1.4 at the wide end and F3.6 at tele, giving 120°~27° horizontal, 63°~15° vertical and 143°~32° diagonal coverage from a minimum object distance of 0.5 m. Alignment and lens settings can be adjusted remotely for a maximum of 200 cycles, with mechanical travel of 0°~350° pan, 0°~85° tilt and 0°~340° rotation. H.265 and H.264 offer up to 120 fps or 100 fps with WDR off and 60 fps or 50 fps with WDR on, while MJPEG delivers 30 fps. Minimum illumination is quoted as 0.01 lux in colour and 0.001 lux in black and white, supported by simple focus, an IR-corrected adaptive P iris and ICR switching. 2 MP resolution (1920 x 1080)Remote pan, tilt and rotate adjustment (max. 200 cycles)2.8~12 mm motorised varifocal lens (4.3x)Up to 120 fps with WDR offIR-corrected adaptive P iris0.01 lux colour, 0.001 lux black and white

The XNV-6083Z is a vandal-resistant AI dome camera whose 1/2.8" CMOS sensor delivers a maximum of 1920 x 1080 pixels (2 MP). A motorised 2.8 to 12 mm varifocal lens provides 4.3x optical zoom, opens to F1.4 wide and F3.6 tele and covers 120°~27° horizontally, 63°~15° vertically and 143°~32° diagonally from 0.5 m. Pan, tilt and rotate can be trimmed remotely for up to 200 cycles across ranges of 0°~350°, 0°~85° and 0°~340°. With WDR off, H.265 and H.264 support up to 120 fps or 100 fps, falling to 60 fps or 50 fps with WDR on, and MJPEG reaches 30 fps. Simple focus and manual focus, an IR-corrected adaptive P iris and ICR switching accompany minimum illumination of 0.01 lux in colour and 0.001 lux in black and white. 2 MP resolution (1920 x 1080)2.8~12 mm motorised varifocal lens (4.3x)Remote pan, tilt and rotate adjustment (max. 200 cycles)Up to 120 fps with WDR offIR-corrected adaptive P irisDay and night (ICR)

The XNV-8083RZ is a vandal-resistant AI IR dome camera whose 1/1.8" CMOS sensor delivers up to 3328 x 1872 pixels (6 MP). Its motorised 4.4 to 9.3 mm varifocal lens with 2.1x optical zoom opens to F1.3 wide and F2.15 tele, giving 113°~47° horizontal, 58°~26° vertical and 138°~54° diagonal coverage from a minimum object distance of 0.5 m. Pan, tilt and rotate travel across 0°~350°, 0°~85° and 0°~340° and can be trimmed remotely for a maximum of 200 cycles. H.265 and H.264 run at up to 30 fps or 25 fps and MJPEG at 30 fps, dropping to 5 fps at 6 MP. Minimum illumination is 0.03 lux in colour and 0.003 lux in black and white, supported by simple focus, manual focus, an IR-corrected P iris and ICR day and night switching. 6 MP resolution (3328 x 1872)4.4~9.3 mm motorised varifocal lens (2.1x)Remote pan, tilt and rotate adjustment (max. 200 cycles)0.03 lux colour, 0.003 lux black and whiteIR-corrected P irisDay and night (ICR)

The vandal-resistant AI dome camera XNV-8083Z captures up to 3328 x 1872 pixels (6 MP) on a 1/1.8" CMOS sensor and encodes H.265 and H.264 at a maximum of 30 fps or 25 fps and MJPEG at 30 fps, limited to 5 fps at 6 MP. Its motorised 4.4~9.3 mm varifocal lens (2.1x optical, F1.3 to F2.15) covers 113°~47° horizontally, 58°~26° vertically and 138°~54° diagonally from 0.5 m under simple focus, manual focus and an IR-corrected P iris. Minimum illumination is 0.03 lux in colour and 0.003 lux in black and white, falling to 0 lux with the IR LED on, while extremeWDR operates at 120 dB alongside ICR switching and the AI-based WiseNRⅡ and WiseStreamⅢ functions. NPU-based analysis identifies people, faces and vehicles including cars, trucks, buses, bicycles and motorcycles as well as licence plates, and adds IVA rules for virtual line and area, enter and exit, loitering, direction and intrusion. The dome bubble is hard-coated, and pan, tilt and rotate span 0°~350°, 0°~85° and 0°~340° with remote adjustment for up to 200 cycles. 6 MP resolution (3328 x 1872)4.4~9.3 mm motorised varifocal lens (2.1x)NPU-based AI object detection with IVA rulesextremeWDR at 120 dBAI-based WiseNRⅡ and WiseStreamⅢHard-coated dome bubble

The XNV-9083RZ is a vandal-resistant AI IR dome camera with a 1/1.8" CMOS sensor and a top resolution of 3840 x 2160 pixels (8 MP). Its motorised 4.4 to 9.3 mm varifocal lens provides 2.1x optical zoom at F1.3 wide and F2.15 tele and covers 113°~47° horizontally, 58°~26° vertically and 138°~54° diagonally from an object distance of 0.5 m. Focus and aperture are handled by simple focus, manual focus and an IR-corrected P iris, together with automatic ICR day and night switching. H.265 and H.264 allow up to 30 fps or 25 fps and MJPEG reaches 30 fps, limited to 5 fps at 8 MP, while minimum illumination is 0.03 lux in colour and 0.003 lux in black and white. Pan, tilt and rotate cover 0°~350°, 0°~85° and 0°~340° and can be trimmed remotely for a maximum of 200 cycles. 8 MP resolution (3840 x 2160)4.4~9.3 mm motorised varifocal lens (2.1x)Remote pan, tilt and rotate adjustment (max. 200 cycles)0.03 lux colour, 0.003 lux black and whiteIR-corrected P irisDay and night (ICR)
