SMQ-7501, 75-Inch 4K Surveillance Display with BNC
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 3-4 days
Matching accessories
The LMK-03 is a tilting steel wall mount kit for displays from 42 to 98 inches. It fits VESA mounting patterns from 75 x 150 mm through to 800 x 500 mm and carries loads up to 100.0 kg. Tilt is specified as -15° to +15°, and installation is straightforward. The profile between display and wall measures just 0.75 mm, and lateral shift together with a safety lock and anti-theft lock is provided. These properties suit the bracket to commercial and public installations. One set weighs 4.4 kg net and 5.1 kg gross, finished in black. Fits 42 to 98 inch displays100.0 kg weight capacityVESA 75 x 150 mm to 800 x 500 mmTilt -15° to +15°0.75 mm profile between display and wallLateral shift, safety and anti-theft lock
Not in stock · delivery 3-4 days
The FMC-07 is a mobile floor mounting cart for displays up to a maximum of 86", rated for 100 kg (220.4 lb). Built as a modular mounting set, it accepts AG Neovo's 55" - 86" large format displays and covers VESA patterns from a minimum of 400 x 200 mm to a maximum of 900 x 600 mm, while the mount rotates through 360°. It comes with a stable tray and lockable castors whose brake and mute design avoids floor scratches and noise. The cart measures 1,240.0 × 1,595.0 × 750.0 mm, stands 1595 mm (62.7") high and weighs 22.1 kg (48.8 lb) net. Materials are Spcc and Aluminium in a silver finish. Floor cart for displays up to 86"100 kg (220.4 lb) weight capacityVESA 400 x 200 mm to 900 x 600 mm360° rotationLockable castors with mute designSpcc and Aluminium, silver
Not in stock · delivery 3-4 days
Product data
- Manufacturer
- AG-Neovo
- Article number
- SMQ-7501
- EAN / GTIN
- 4710739598124
Description
This durable 75-inch 4K surveillance display uses an IPS panel with a 0.430 mm pixel pitch, suits continuous control-room operation and works with analogue as well as digital surveillance systems. Camera image quality up to 8MP is supported, which helps when zooming into recorded footage. Brightness reaches 450 cd/m² and the surface combines anti-glare treatment at haze 1% with a 3H hard coating. Video enters on one composite BNC input and leaves on one composite BNC output, while two 15 W speakers reproduce audio. The internal power supply runs on AC 100-240V at 50/60 Hz, drawing 201 W in on mode and under 0.5 W on standby; the unit weighs 38.0 kg without base and mounts to VESA 800 x 400 mm.
- IPS panel, 0.430 mm pixel pitch
- 450 cd/m² brightness
- Anti-glare haze 1% with 3H hard coating
- 15 W x 2 internal speakers
- 201 W (On), under 0.5 W standby
- VESA 800 x 400 mm
Made by
AG Neovo builds displays for continuous operation: surveillance monitors with 24/7 rating, metal housing and burn-in protection from 10 to 55 inches, public view monitors with a built-in camera, stretched displays for video walls, 4K digital signage, interactive smartboards with AI camera, plus workstations and mounts. Every model comes with technical data, data sheet, manual and certificates. AI4Vision is an authorised distributor; trade prices after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
- Brightness
- 22.4kg (49.38lb), 350~499 cd/㎡
- Composite
- BNC x 1
- Internal Speakers
- 15W x 2
- On Mode
- 201W (On)
- Packaging
- 50.0 kg (110.2 lb)
- Panel Type
- IPS
- Pixel Pitch
- 0.430 mm
- Power Requirements
- AC 100-240V, 50/60 Hz
- Power Supply
- Internal
- Product w/o Base
- 38.0 kg (83.78 lb)
- Sizes
- 46"-55"
- Standby Mode
- < 0.5W
- Surface Treatment
- Anti-Glare Treatment (Haze 1%), 3H Hard Coating
- VESA FPMPMI
- Yes (800 x 400 mm)
