SMQ-6501, 65-Inch 4K Surveillance Display with BNC
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 3-4 days
Matching accessories
The LMK-01 is a steel wall mount kit for displays from 42 to 86 inches. It carries loads up to 80.0 kg and supports mounting patterns of up to 725.0 x 450.0 mm. A tilt range of -15° to 0° lets the screen be angled downwards. The anodised black steel build is rust resistant and intended for indoor as well as outdoor use, and it can be fixed to masonry walls as well as to lightweight partition walls. One set weighs 5.1 kg net and 5.9 kg gross, in packaging measuring 836.0 x 245.0 x 54.0 mm. Fits 42 to 86 inch displays80.0 kg weight capacityTilt -15° to 0°Mounting pattern up to 725.0 x 450.0 mmSteel construction, black5.1 kg net weight
Not in stock · delivery 3-4 days
The LMK-03 is a tilting steel wall mount kit for displays from 42 to 98 inches. It fits VESA mounting patterns from 75 x 150 mm through to 800 x 500 mm and carries loads up to 100.0 kg. Tilt is specified as -15° to +15°, and installation is straightforward. The profile between display and wall measures just 0.75 mm, and lateral shift together with a safety lock and anti-theft lock is provided. These properties suit the bracket to commercial and public installations. One set weighs 4.4 kg net and 5.1 kg gross, finished in black. Fits 42 to 98 inch displays100.0 kg weight capacityVESA 75 x 150 mm to 800 x 500 mmTilt -15° to +15°0.75 mm profile between display and wallLateral shift, safety and anti-theft lock
Not in stock · delivery 3-4 days
The LMA-02 is a full-motion extendable wall mount bracket for displays from 32 to 65 inches, rated for loads up to 50.0 kg. Its arm extends from a wall distance of 64.0 mm out to 510.0 mm, so the screen can be positioned freely within a room. Viewing angles are refined through -20° to +10° of tilt and 60° of swivel to the right and left. The all-metal construction is finished in black and accepts mounting patterns up to 600 x 400 mm. One set weighs 7.0 kg net and 7.5 kg gross, packed in a carton measuring 700.0 x 222.0 x 70.0 mm. Fits 32 to 65 inch displays50.0 kg weight capacityExtension 64.0 mm to 510.0 mmTilt -20° to +10°Swivel 60° / 60°Mounting pattern up to 600 x 400 mm
Not in stock · delivery 3-4 days
Product data
- Manufacturer
- AG-Neovo
- Article number
- SMQ-6501
- EAN / GTIN
- 4710739597400
Description
Built around a 64.5-inch IPS panel with a 0.372 mm pixel pitch, this durable 65-inch 4K surveillance display integrates with analogue and digital surveillance systems alike. It is intended for nonstop professional control-room use with camera image quality up to 8MP, keeping footage readable when zoomed in. Brightness is 350~499 cd/㎡, and anti-burn-in technology, HeatControl and a metal casing are part of the design. Connections cover audio, composite (BNC), DVI-D, HDMI, RS232, USB Type-A and VGA as inputs, audio, composite (BNC) and S/PDIF as outputs, plus daisy chain, RJ45 and RS232 on a 9-pin D-Sub for external control. Without base the display measures 1476.7 x 851.7 x 79.8 mm at 26.0 kg, draws 123 W in on mode and mounts to VESA 600 x 400 mm.
- 64.5-inch IPS panel, 0.372 mm pixel pitch
- 350~499 cd/㎡ brightness
- Anti-burn-in, HeatControl, metal casing
- 10 W x 2 speakers and S/PDIF output
- 123 W (On) power consumption
- VESA 600 x 400 mm
Made by
AG Neovo builds displays for continuous operation: surveillance monitors with 24/7 rating, metal housing and burn-in protection from 10 to 55 inches, public view monitors with a built-in camera, stretched displays for video walls, 4K digital signage, interactive smartboards with AI camera, plus workstations and mounts. Every model comes with technical data, data sheet, manual and certificates. AI4Vision is an authorised distributor; trade prices after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
- Anti-Burn-in
- Yes
- Aspect Ratio
- 16:9
- Audio In
- Stereo Audio Jack (3.5 mm)
- Audio Out
- S/PDIF, Stereo Audio Jack (3.5 mm)
- Brightness
- 350~499 cd/㎡, 400 cd/m²
- Casing Colour
- Black
- Certifications & Compliance
- CE, LVD, WEEE, RoHS, REACH, UKCA
- Colour Gamut
- NTSC 72%
- Composite
- BNC x 1
- Composite (CVBS)
- BNC x 1
- Contrast Ratio
- 1200:1
- DVI
- 24-Pin DVI-D
- Diagonal Sizes
- 32"-43"
- Display Colour
- 1.07B
- External Control
- Daisy Chain
- Features
- 24-7, HeatControl, Speaker
- Frequency (H)
- 15KHz~135KHz
- Frequency (V)
- 24Hz ~ 86 Hz
- HDMI
- 2.0 x 1
- Humidity
- 10%-95% (non-condensing), 20%-85% (non-condensing)
- IK Rating
- LMA-02, LMK-01, LMK-03
- Innovation
- Anti-Burn-in Technology, Metal Casing
- Inputs
- Audio, Composite (BNC), DVI-D, HDMI, RS232, USB Type-A, VGA
- Internal Speakers
- 10W x 2
- LAN
- RJ45 x 1
- Max. Resolution
- UHD 3840 x 2160
- On Mode
- 123W (On)
- Operating Time (Internal)
- 24/7
- Orientation
- Landscape only
- Outputs
- Audio, Composite (BNC)
- Packaging
- 36.5 kg (80.5 lb)
- Packaging (W x H x D)
- 1660.0 x 1045.0x 220.0 mm (65.4" x41.1" x8.7")
- Panel Size
- 64.5"
- Panel Size on Carton
- 65.0"
- Panel Type
- IPS
- Pixel Pitch
- 0.372 mm
- Power Requirements
- AC 100-240V, 50/60 Hz
- Power Supply
- Internal
- Product w/o Base
- 26.0 kg (57.3 lb)
- Product w/o Base (W x H x D)
- 1476.7 x 851.7 x 79.8 mm (58.1" x 33.5" x 3.1")
- RS232 In
- 9-Pin D-Sub
- Rear Cover Material
- Metal
- Resolution
- FHD 1920 x 1080 (16:9)
- Response Time
- 5 ms
- Standby Mode
- < 0.5W
- Supplied
- HDMI Cable, Power Cord, Quick Start Guide, Remote Control
- Surface Treatment
- Anti-Glare Treatment (Haze 1%), 3H Hard Coating
- Temperature
- -10°C-60°C (14°F-140°F), 0°C-40°C (32°F-104°F)
- USB
- DC 12V, 1.75A
- VESA FPMPMI
- Yes (600 x 400 mm)
- VGA
- 15-Pin D-Sub x 1
- Viewing Angle (H/V)
- 178°/178°
- Viewing Angles
- 178/178
- Visibility
- Gamma Selection
