Remote Head Housing
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 3-4 days
Fits
The SLA-T2480A is a 2MP lens module combining a 1/2.8-inch CMOS sensor with a fixed 2.4 mm lens at F2.0. Coverage amounts to 138° horizontally, 73° vertically and 165° diagonally, and minimum illumination is 0.045 lux in both colour and black-and-white. Focus is fixed and the module attaches to the main unit over RJ12. The black plastic body measures Ø24 x 49.8 mm and weighs 318 g, with an operating range of -10 °C to +55 °C. Supported products are the XNB-6002, PNM-9000QB, PNM-C20000QB and XNB-A8004B, using the SCL-150 lens module cable at 15 m. Fixed 2.4 mm focal length, F2.0138° x 73° x 165° field of view1/2.8-inch CMOS, 0.045 luxPlastic body Ø24 x 49.8 mm, 318 gRJ12 connection to the main unitSCL-150 lens module cable (15 m)
Not in stock · delivery 3-4 days
The SLA-T4680A is a 2MP lens module pairing a 1/2.8-inch CMOS sensor with a fixed 4.6 mm lens at F2.5. It covers 73° horizontally, 39° vertically and 85° diagonally, and minimum illumination is 0.06 lux in colour as well as black-and-white. Focus is fixed and the main unit is connected over RJ12. The black plastic body measures Ø24 x 49.8 mm and weighs 310 g, with an operating range from -10 °C to +55 °C. Supported products are the XNB-6002, PNM-9000QB, PNM-C20000QB and XNB-A8004B. Fixed 4.6 mm focal length, F2.573° x 39° x 85° field of view1/2.8-inch CMOS, 0.06 luxPlastic body Ø24 x 49.8 mm, 310 gRJ12 connection to the main unitSCL-150 lens module cable (15 m)
Not in stock · delivery 3-4 days
Product data
- Manufacturer
- Hanwha Vision
- Article number
- SBL-101C
- EAN / GTIN
- 8801089212023
- Weight
- 0.2 kg
- Dimensions (W×H×D)
- 143 × 143 × 118 mm
Description
The SBL-101C is a polycarbonate housing for remote head cameras. Its finish is white to RAL9003. The unit measures 124.3mm wide, 115mm deep and 56mm high, with a weight of 90g. It accepts the SLA-T2480 and SLA-T2480A camera modules. For models beyond those, the manufacturer refers to its website and its Toolbox.
- Housing for remote head cameras
- Polycarbonate, white RAL9003
- 124.3x115x56mm, 90g
- For SLA-T2480 and SLA-T2480A
Made by
Hanwha Vision (formerly Hanwha Techwin, the Wisenet brand) is the largest manufacturer in the AI4Vision catalogue: dome, bullet, PTZ, fisheye, multi-sensor and thermal cameras, network recorders, the Wisenet WAVE video management system, encoders and decoders, monitors, IP audio, intercom and access controllers, plus mounts and housings. The P and X series cameras carry AI video analytics on board. As an authorised distributor, AI4Vision carries the Wisenet range with technical data and manufacturer data sheets; trade partners see prices and availability after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Mechanical (5)
- Mechanical – Color
- White
- Mechanical – Material
- PC(Polycarbonate)
- Mechanical – RAL Code
- RAL9003
- Product dimensions / weight
- 124.3x115x56mm(4.89x4.53x2.2") / 90g(0.198lb)
- Supported products
- SLA-T2480, SLA-T2480A ※ For further compatible models, please visit our website or use Toolbox
