IP-CAMERA SD9387-EHL

The AJ-001 is a USB joystick carrying eight keys for operating video surveillance equipment. Positioning control runs through a Hall effect three axes joystick (X/Y/Z), with joystick travel of +/-20 on the X and Y axes and +/-30 on the Z axis. Eight long life tactile switches and three LED indicators complete the control surface, all held in a high impact ABS housing. Power and data both arrive over the USB interface at 5V DC with 100mA consumption, connected via USB2.0 (USB Type A Male). Windows 7/8/10/11 are supported with plug & play, as are all VIVOTEK NVR, Speed Dome and VSS platforms. The unit measures 120 (W) x 157 (L) x 97 (H) mm, weighs 0.6 kg and operates from -25°C to 60°C (-13°F to 140°F). Hall effect three axes joystick, X/Y/Z8 long life tactile switches, 3 LED indicatorsHigh impact ABS housingUSB2.0 Type A, 5V DC / 100mAWindows 7/8/10/11 plug & playOperating temperature -25°C to 60°C

AC-21A is a smoked cover for PTZ cameras, moulded in PC and supplied in a smoked finish. It measures Ø176 x 85 mm and weighs 143 g. Packing is identical for box and carton at 474 (L) x 406 (W) x 262 (H) mm for 8 pieces with a weight of 3881 g. The cover is listed for the SD9367-EHL and SD9387-EHL models. Smoked cover for PTZ camerasPC material, smoked finishØ176 x 85 mm, 143 gListed for SD9367-EHL and SD9387-EHL

Listed under part number VIO900000048, the AM-21P is a wall mount bracket intended for easy installation. The part is produced in aluminum alloy with a white finish, measures 350 (L) x 180 (W) x 211 (H) mm and has an own weight of 1,780 g. Both the box and the carton are given as 388 (L) x 258 (W) x 234 (H) mm at 5,000g. Compatibility is stated for the models SD9368-EHL, SD9384-EHL and SD9394-EHL. Aluminum alloy wall mount bracketWhite finishDimensions 350 x 180 x 211 mmOwn weight 1,780 gSupports SD9368-EHL, SD9384-EHL, SD9394-EHL

The AM-220 is a wall mount bracket made of aluminium alloy in a white finish. It measures 297 mm in length, 140 mm in width and 200 mm in height, and weighs 1212 g. Single-unit packaging measures 350 x 250 x 180 mm at 1780 g, while the six-piece carton measures 540 x 550 x 380 mm and weighs 12130 g. The manufacturer lists the bracket under part number 900030100G. Supported models stated include SD9361-EHL, SD9362-EH, SD9362-EHL, SD9362-EH-V2, SD9363-EHL, SD9364-EH, SD9364-EHL, SD9365-EHL, SD9366-EH and SD9364-EH-V2. Wall mount bracket in aluminium alloyWhite colourDimensions 297 x 140 x 200 mmWeight 1212 gPart number 900030100G

The AM-314 is a pole mount adapter sized for poles of 89~152.4mm. SECC and stainless steel are used for its construction, with a white finish. At 240 (L) x 156.7 (W) x 68.9 (H) mm and 1260g, the adapter stays comparatively compact. Models supported include SD9361-EHL, SD9362-EH, SD9363-EHL, SD9364-EHL, SD9365-EHL, SD9366-EHL and SD9368-EHL. Box dimensions are 240 (L) x 160 (W) x 70 (H) mm and the carton measures 355 (L) x 255 (W) x 490 (H) mm. Pole mount adapter for 89~152.4mm polesSECC and stainless steel, white finishDimensions 240 x 156.7 x 68.9 mmWeight 1260gSupports SD9361-EHL to SD9368-EHL speed domes

The AM-414 is a corner mount adapter for installations in building corners. It is produced from SPCC and painted white. Dimensions are 240 (L) x 341.6 (W) x 233.4 (H) mm with a weight of 3130g. Listed supported models include SD9361-EHL, SD9362-EH, SD9363-EHL, SD9364-EHL, SD9365-EHL, SD9366-EHL and SD9368-EHL. For transport, single packaging measures 247 (L) x 358 (W) x 132 (H) mm at 4360g, while the four-piece carton comes to 365 (L) x 560 (W) x 270 (H) mm and 18440g. Corner mount adapterSPCC material, white finishDimensions 240 x 341.6 x 233.4 mmWeight 3130gSupports SD9361-EHL to SD9368-EHL speed domes

Gooseneck mounting bracket

Pendant Pipe (20cm) (1.5" PS11)

As a combo cable for speed domes, the AO-008 brings audio and control connections together. It offers an audio input and audio output, an RS485 interface as well as two digital inputs and one digital output. At 57 cm in length the item weighs 44 g and is listed under part number 631443000G. The models named as compatible are SD9368-EHL, SD9384-EHL and SD9394-EHL. Combo cable for speed domeAudio input and audio outputRS485 interface2 digital inputs, 1 digital outputLength 57 cm, weight 44 g

The AM-117 is a pendant pipe of 40cm length with a 1-1/2" PS thread, held in version V02 under part number 900014401G. It is produced from aluminum alloy with a white finish and carries a PF 1-1/2" pipe thread. Dimensions are Ø 51 x 400 mm at an own weight of 902g. A single box measures 470 (L) x 71 (W) x 68 (H) mm and weighs 1014g. A carton holds 10 pieces, measures 490 (L) x 365 (W) x 160 (H) mm and weighs 10870g. 40cm pendant pipeAluminum alloy, white finishPF 1-1/2" pipe threadDimensions Ø 51 x 400 mmOwn weight 902g

Pendant head (outdoor)

Parapet mounting bracket for Speeddome

The AM-315 is a pole mount adapter covering poles of 100~230mm. It is manufactured from SPCC and finished in white. Dimensions come to 240 (L) x 275 (W) x 136~280.7 (H) mm at a weight of 4850g, so the height adapts to the pole in question. Supported models include the SD9361-EHL, SD9362-EH, SD9363-EHL, SD9364-EHL, SD9365-EHL, SD9366-EHL and SD9368-EHL speed domes among others. Packaging measures 240 (L) x 160 (W) x 70 (H) mm, and the shipping carton 500 (L) x 170 (W) x 340 (H) mm at 11900g. Pole mount adapter for 100~230mm polesSPCC material, white finishDimensions 240 x 275 x 136~280.7 mmWeight 4850gSupports SD9361-EHL to SD9368-EHL speed domes

The AM-529 is a mounting adapter for speed dome cameras. It is made of aluminum alloy, finished in white, and measures Ø154 x 72 mm at 460g. On the thread side it offers a 3/4" NPT female and a 1-1/2" PS male connection. Single-unit packaging measures 155 (L) x 155 (W) x 79 (H) mm at 491g, while a 20-piece carton measures 364 (L) x 339 (W) x 464 (H) mm at 10820g. Supported models are SD9361-EHL, SD9362-EH, SD9362-EHL, SD9363-EHL, SD9364-EH, SD9364-EHL, SD9365-EHL, SD9366-EH, SD9362-EH-V2 and SD9363-EHL-V2, under part number 900032400G. Mounting adapter for speed domeAluminum alloy, white3/4" NPT female and 1-1/2" PS male threadØ154 x 72 mm460gSupports SD9361 to SD9366 models

The AM-718 is a waterproof junction box for cable routing at camera installations. It is manufactured from aluminum and SPCC in white, and its casing is classified IP67 and IK10. Outer measurements are 255 (L) x 200 (W) x 130 (H) mm at a weight of 2020g. Single-unit packaging measures 315 (L) x 258 (W) x 188 (H) mm and weighs 2650g, while a four-piece carton comes to 534 (L) x 330 (W) x 397 (H) mm at 11600g. Supported models include SD9361-EHL, SD9362-EH, SD9363-EHL, SD9364-EHL, SD9365-EHL, SD9366-EHL and SD9368-EHL among others. Waterproof junction boxAluminum and SPCC, white finishCasing rated IP67, IK10Dimensions 255 x 200 x 130 mmWeight 2020g

The AM-10I is a recessed kit for PTZ cameras, listed under part number VIO900000091. Its bracket is made of SECC and the cover of PC, both in white. The kit measures ⌀255 x 103.9 mm and weighs 1200g. Box and carton are each specified as 320 (L) x 318 (W) x 184 (H) mm at 1900g. The models supported are SD9367-EHL and SD9387-EHL. Recessed kit for PTZ camerasBracket SECC, cover PCWhite finish⌀255 x 103.9 mm, 1200gFor SD9367-EHL and SD9387-EHL
