Dome Back box

The XNV-6080 is a vandal-resistant network dome camera whose 1/2.8" CMOS sensor resolves up to 1920 x 1080 pixels (2 MP). Its motorised varifocal lens spans 2.8 to 12 mm (4.3x optical) at F1.4 wide and F3.6 tele, covering 119.5°~27.9° horizontally, 62.8°~15.7° vertically and 142.1°~32.0° diagonally from a minimum object distance of 0.5 m. Focusing is available as simple focus or manual, and iris control uses DC auto iris and P iris. H.265 and H.264 reach 60 fps and MJPEG 30 fps, with minimum illumination of 0.015 lux in colour and 0.0015 lux in black and white. ICR switching, wide dynamic range up to 150 dB, defog, an SD/SDHC/SDXC slot for up to 512 GB and adjustment ranges of 0°~354°, 0°~67° and 0°~355° complete the specification. 2 MP resolution (1920 x 1080)2.8~12 mm motorised varifocal lens (4.3x)Wide dynamic range up to 150 dB with defogSimple focus, DC auto iris and P irisSD/SDHC/SDXC slot up to 512 GBUp to 60 fps in H.265/H.264

The XNV-6080R is a vandal-resistant IR network dome camera using a 1/2.8" CMOS sensor with a maximum of 1920 x 1080 pixels (2 MP). Its motorised 2.8~12 mm varifocal lens (4.3x optical, F1.4 wide) covers 119.5°~27.9° horizontally, 62.8°~15.7° vertically and 142.1°~32.0° diagonally and uses simple focus from 0.5 m, with IR-corrected DC auto iris and P iris. Frame rates reach 60 fps in H.265 and H.264 and 30 fps in MJPEG, while minimum illumination is 0.015 lux in colour and 0.0015 lux in black and white. Image processing includes ICR day and night switching, wide dynamic range up to 150 dB, DWDR, BLC, HLC, SSDR and defog. Recordings can be held on SD/SDHC/SDXC cards up to 512 GB, and adjustment covers 0°~354°, 0°~67° and 0°~355°. 2 MP resolution (1920 x 1080)2.8~12 mm motorised varifocal lens (4.3x)IR-corrected DC auto iris and P irisWide dynamic range up to 150 dB, DWDR, SSDRSD/SDHC/SDXC slot up to 512 GBDefog and day/night (ICR)

The XNV-8080R is a vandal-resistant IR network dome camera with a 1/1.8" CMOS sensor and up to 2560 x 1920 pixels (5 MP). Its motorised varifocal lens spans 3.9 to 9.4 mm (2.4x optical) and opens to F1.3 wide and F2.4 tele, covering 92.1°~38.7° horizontally, 67.2°~29.0° vertically and 119.9°~48.6° diagonally from 0.5 m. Simple focus, a DC auto iris and an IR-corrected P iris handle focusing and exposure. H.265 and H.264 deliver up to 30 fps or 25 fps and MJPEG 30 fps, with minimum illumination of 0.07 lux in colour and 0.007 lux in black and white. ICR switching, wide dynamic range up to 120 dB, defog, an SD/SDHC/SDXC slot for up to 512 GB and adjustment of 0°~354°, 0°~67° and 0°~355° complete the camera. 5 MP resolution (2560 x 1920)3.9~9.4 mm motorised varifocal lens (2.4x)Wide dynamic range up to 120 dB with defogSimple focus with IR-corrected P irisSD/SDHC/SDXC slot up to 512 GB0.07 lux colour, 0.007 lux black and white
