Dome Back Box

The HCV-6070R is a vandal-resistant analog HD dome camera with infrared illumination, built to IP66 and IK10. Its 1/2.8-inch CMOS sensor produces 1920x1080 at 30fps (NTSC) or 25fps (PAL), and the 3.2 to 10mm varifocal lens with 3.1x optical zoom covers 110.2° to 32° horizontally, 55.4° to 18° vertically and 128.4° to 36.6° diagonally. Focus is manual by way of an IR-corrected DC auto iris from a minimum object distance of 0.5m. At F1.6 the camera is rated 0.11 lux in colour and 0.011 lux in black and white, reaching 0 lux with the IR LED on and a 30m viewable length. The BNC output supplies AHD, TVI, CVI or CVBS over up to 500m of 5C2V coaxial cable, an automatic ICR filter handles day and night switching, and 120dB WDR, SSNRⅣ and motion detection support the image. Within the housing the module pans 0° to 350°, tilts 0° to 67° and rotates 0° to 355°, with plug-and-play installation and dual power. Vandal-resistant IP66 and IK10 housing3.2 to 10mm varifocal lens (3.1x)1/2.8-inch CMOS sensor, 1920x108030m IR viewable length, 0 lux with IR LED120dB WDR, SSNRⅣ, motion detectionAHD/TVI/CVI/CVBS BNC output up to 500m

The QNV-6082R is a network dome camera with infrared illumination that delivers a maximum of 1920x1080 from a 1/2.8" CMOS sensor. Its varifocal lens runs from 3.2 to 10 mm (3.1x) at F1.6 wide and F2.9 tele, uses a DC auto iris with simple focus and covers 109 to 33 degrees horizontally, 58 to 18 degrees vertically and 132 to 38 degrees diagonally from 0.5 m. Streaming is available in H.265, H.264 and MJPEG at 30fps/25fps (60Hz/50Hz) and 15fps respectively, with a maximum of 4fps at 2MP and several streams at once. At 1/30 sec and 30 IRE the camera reaches 0.03 lux in colour and 0.003 lux in black and white, with day/night switching handled automatically by ICR. Motion, tampering and defocus detection, hallway view at 90 and 270 degrees, LDC and a Micro SD/SDHC/SDXC slot for up to 128 GB round out the specification, while alignment allows 0 to 350 degrees of pan, 0 to 67 degrees of tilt and 0 to 355 degrees of rotation. 3.2 to 10 mm varifocal lens (3.1x)1/2.8" CMOS, max. 1920x10800.03 lux colour / 0.003 lux BWSimple focus with DC auto irisHallway view 90/270 degrees, LDCMicro SD/SDHC/SDXC up to 128 GB
