Wall&Pole Mount

The TNO-4050T resolves thermal scenes at 640x480, with 640x360 and 320x240 available as alternatives. Its uncooled micro bolometer uses a 17 µm pixel pitch, a thermal sensitivity of ≤50 mK and the 8~14 µm spectral band, and frame rates reach 30/25 fps (60/50 Hz) in H.265 and H.264 as well as 30 fps in MJPEG. A fixed 35 mm F1.0 lens sits in front of the sensor and covers 17.2° horizontally, 13° vertically and 22° diagonally, for an iFoV of 0.47 mRad and a minimum object distance of 36 m. Analytics include motion detection with handover, tampering and loitering detection, directional detection, audio detection, sound classification, and detection of shock and temperature change. An SD/SDHC/SDXC slot takes up to 256 GB of recordings, and Hallway View and WiseStream II are supported. Uncooled micro bolometer, 640x480, 17 µmNETD ≤50 mK, 8~14 µm spectral range35 mm fixed lens, F1.0, field of view 17.2° x 13°Up to 30/25 fps in H.265 and H.264Shock and temperature change detectionSD/SDHC/SDXC up to 256 GB

A 640x480 uncooled micro bolometer with a 17 µm pixel size drives the TNO-C4040T, which outputs 1280x960, 640x480, 640x360 or 320x240. Across the 8–14 µm spectral range, sensitivity is specified as NETD ≤16 mK at 25 °C, F1.0. The athermalized 13 mm fixed lens at F1.0 spans 49.1° horizontally and 36.4° vertically, 62.3° on the diagonal, with an iFoV of 1.31 mRad and a minimum object distance of 5 m (16.4 ft). H.265 and H.264 reach 30fps/25fps (60Hz/50Hz) and MJPEG 30fps. WiseNR digital noise reduction conditions the image, and eight zones are available for motion detection. An SD/SDHC/SDXC slot takes cards of up to 256 GB, Hallway View and WiseStream II are supported, power comes from PoE, 24 V AC or 12 V DC, and the housing is rated IP66, NEMA4X and IK10. Uncooled micro bolometer 640x480Athermalized 13 mm fixed lens, F1.0NETD ≤16 mK at 25 °CUp to 30fps/25fps (60Hz/50Hz) (H.265/H.264)SD/SDHC/SDXC slot up to 256 GBIP66, NEMA4X, IK10

A 640x480 uncooled micro bolometer with a 17 µm pixel size drives the TNO-C4042T, which outputs 1280x960, 640x480, 640x360 or 320x240. Across the 8–14 µm spectral range, sensitivity is specified as NETD ≤16 mK at 25 °C, F1.0. The athermalized 13 mm fixed lens at F1.0 spans 49.1° horizontally and 36.4° vertically, 62.3° on the diagonal, with an iFoV of 1.31 mRad and a minimum object distance of 5 m (16.4 ft). H.265 and H.264 reach 8fps and MJPEG 8fps. WiseNR digital noise reduction conditions the image, and eight zones are available for motion detection. Persons, vehicles and vessels are detected, and the image can be upscaled to 1280x960. Uncooled micro bolometer 640x480Athermalized 13 mm fixed lens, F1.0NETD ≤16 mK at 25 °CUp to 8fps (H.265/H.264)Person, vehicle and vessel detectionMIL-STD, NEMA 4X, NEMA TS rated

A 640x480 uncooled micro bolometer with a 17 µm pixel size drives the TNO-C4050T, which outputs 1280x960, 640x480, 640x360 or 320x240. Across the 8–14 µm spectral range, sensitivity is specified as NETD ≤16 mK at 25 °C, F1.0. The athermalized 19 mm fixed lens at F1.0 spans 32.8° horizontally and 24.6° vertically, 41.1° on the diagonal, with an iFoV of 0.89 mRad and a minimum object distance of 11 m (36.1 ft). H.265 and H.264 reach 30fps/25fps (60Hz/50Hz) and MJPEG 30fps. WiseNR digital noise reduction conditions the image, and eight zones are available for motion detection. The image can be upscaled to 1280x960, and the camera carries MIL-STD, NEMA 4X and NEMA TS ratings. Uncooled micro bolometer 640x480Athermalized 19 mm fixed lens, F1.0NETD ≤16 mK at 25 °CUp to 30fps/25fps (60Hz/50Hz) (H.265/H.264)Upscaling to 1280x960MIL-STD, NEMA 4X, NEMA TS rated

A 640x480 uncooled micro bolometer with a 17 µm pixel size drives the TNO-C4052T, which outputs 1280x960, 640x480, 640x360 or 320x240. Across the 8–14 µm spectral range, sensitivity is specified as NETD ≤16 mK at 25 °C, F1.0. The athermalized 19 mm fixed lens at F1.0 spans 32.8° horizontally and 24.6° vertically, 41.1° on the diagonal, with an iFoV of 0.89 mRad and a minimum object distance of 11 m (36.1 ft). H.265 and H.264 reach 8fps and MJPEG 8fps. WiseNR digital noise reduction conditions the image, and eight zones are available for motion detection. Persons, vehicles and vessels are detected, and the image can be upscaled to 1280x960. Uncooled micro bolometer 640x480Athermalized 19 mm fixed lens, F1.0NETD ≤16 mK at 25 °CUp to 8fps (H.265/H.264)Person, vehicle and vessel detectionMIL-STD, NEMA 4X, NEMA TS rated

A 640x480 uncooled micro bolometer with a 17 µm pixel size drives the TNO-C4060T, which outputs 1280x960, 640x480, 640x360 or 320x240. Across the 8–14 µm spectral range, sensitivity is specified as NETD ≤16 mK at 25 °C, F1.0. The athermalized 35 mm fixed lens at F1.0 spans 17.5° horizontally and 13.2° vertically, 21.7° on the diagonal, with an iFoV of 0.47 mRad and a minimum object distance of 36 m (118.1 ft). H.265 and H.264 reach 30fps/25fps (60Hz/50Hz) and MJPEG 30fps. WiseNR digital noise reduction conditions the image, and eight zones are available for motion detection. The image can be upscaled to 1280x960, and the camera carries MIL-STD, NEMA 4X and NEMA TS ratings. Uncooled micro bolometer 640x480Athermalized 35 mm fixed lens, F1.0NETD ≤16 mK at 25 °CUp to 30fps/25fps (60Hz/50Hz) (H.265/H.264)Upscaling to 1280x960MIL-STD, NEMA 4X, NEMA TS rated

A 640x480 uncooled micro bolometer with a 17 µm pixel size drives the TNO-C4062T, which outputs 1280x960, 640x480, 640x360 or 320x240. Across the 8–14 µm spectral range, sensitivity is specified as NETD ≤16 mK at 25 °C, F1.0. The athermalized 35 mm fixed lens at F1.0 spans 17.5° horizontally and 13.2° vertically, 21.7° on the diagonal, with an iFoV of 0.47 mRad and a minimum object distance of 36 m (118.1 ft). H.265 and H.264 reach 8fps and MJPEG 8fps. WiseNR digital noise reduction conditions the image, and eight zones are available for motion detection. Persons, vehicles and vessels are detected, and the image can be upscaled to 1280x960. Uncooled micro bolometer 640x480Athermalized 35 mm fixed lens, F1.0NETD ≤16 mK at 25 °CUp to 8fps (H.265/H.264)Person, vehicle and vessel detectionMIL-STD, NEMA 4X, NEMA TS rated

A 640x480 uncooled micro bolometer with a 17 µm pixel size drives the TNO-C4080T, which outputs 1280x960, 640x480, 640x360 or 320x240. Across the 8–14 µm spectral range, sensitivity is specified as NETD ≤16 mK at 25 °C, F1.0. The athermalized 60 mm fixed lens at F1.15 spans 10.3° horizontally and 7.7° vertically, 12.8° on the diagonal, with an iFoV of 0.28 mRad and a minimum object distance of 92 m (301.8 ft). H.265 and H.264 reach 30fps/25fps (60Hz/50Hz) and MJPEG 30fps. WiseNR digital noise reduction conditions the image, and eight zones are available for motion detection. The image can be upscaled to 1280x960, and the camera carries MIL-STD, NEMA 4X and NEMA TS ratings. Uncooled micro bolometer 640x480Athermalized 60 mm fixed lens, F1.15NETD ≤16 mK at 25 °CUp to 30fps/25fps (60Hz/50Hz) (H.265/H.264)Upscaling to 1280x960MIL-STD, NEMA 4X, NEMA TS rated

A 640x480 uncooled micro bolometer with a 17 µm pixel size drives the TNO-C4082T, which outputs 1280x960, 640x480, 640x360 or 320x240. Across the 8–14 µm spectral range, sensitivity is specified as NETD ≤16 mK at 25 °C, F1.0. The athermalized 60 mm fixed lens at F1.15 spans 10.3° horizontally and 7.7° vertically, 12.8° on the diagonal, with an iFoV of 0.28 mRad and a minimum object distance of 92 m (301.8 ft). H.265 and H.264 reach 8fps and MJPEG 8fps. WiseNR digital noise reduction conditions the image, and eight zones are available for motion detection. Persons, vehicles and vessels are detected, and the image can be upscaled to 1280x960. Uncooled micro bolometer 640x480Athermalized 60 mm fixed lens, F1.15NETD ≤16 mK at 25 °CUp to 8fps (H.265/H.264)Person, vehicle and vessel detectionMIL-STD, NEMA 4X, NEMA TS rated

The XND-A8085RV is a modular 5MP AI IR dome camera built on a 1/2.8" CMOS sensor with a top resolution of 2560x1920. A motorised 3.3 to 9.3 mm varifocal lens with 2.8x zoom and an IR-corrected P iris works at F1.3 wide and F2.3 tele, covering 99° to 31° horizontally, 71° to 23° vertically and 133° to 39° diagonally from a 0.5 m minimum object distance. Frame rates are 30fps/25fps (60Hz/50Hz) in H.265 and H.264, with MJPEG at 30fps and a maximum of 5fps at 5MP. Minimum illumination is stated as 0.04 lux in colour and 0.004 lux in black-and-white, and an ICR handles day and night switching automatically. A tilt range of -45° to 85° together with 0° to 360° pan and 0° to 355° rotation allows flexible alignment, and focusing is by simple focus. Modular design, 5MPMotorised 3.3–9.3 mm varifocal lens, 2.8xIR-corrected P iris, F1.3 to F2.3Tilt range -45° to 85°0.04 lux colour, 0.004 lux B/WICR day and night switching

In a modular design, the XND-A9085RV is an 8MP AI IR dome camera delivering up to 3840x2160 from a 1/1.8" CMOS sensor. Its motorised 4.4 to 9.3 mm varifocal lens works with 2.1x zoom, an IR-corrected P iris, F1.3 wide and F2.15 tele, covering 113° to 47° horizontally, 58° to 26° vertically and 138° to 54° diagonally, with a minimum object distance of 0.5 m. H.265 and H.264 run at 30fps/25fps (60Hz/50Hz) and MJPEG at 30fps, limited to 5fps at 8MP. Minimum illumination is given as 0.04 lux in colour and 0.004 lux in black-and-white, and an ICR performs day and night switching. Tilt ranges from -45° to 85°, complemented by 0° to 360° pan and 0° to 355° rotation, and focusing is by simple focus. Modular design, 8MP1/1.8" CMOS, up to 3840x2160Motorised 4.4–9.3 mm varifocal lens, 2.1xIR-corrected P iris, F1.3 to F2.15Tilt range -45° to 85°0.04 lux colour, 0.004 lux B/W
