TX-2202A, 22'' 10-Point Touch Screen Monitor
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 3-4 days
Matching accessories
The PMK-01 is an ergonomic wall mount kit for displays from 15 to 32 inches with a load capacity of 14.0 kg. Three pivots deliver 270° of rotation, tilt from -90° to +90° and 90° of swivel to each side. Supported VESA patterns are 75 x 75 mm and 100 x 100 mm. The bracket is made of steel and die-cast aluminium with an electronic dipping finish in black. Product dimensions are 115.0 x 115.0 x 131.0 mm, and one set weighs 1.5 kg net and 1.6 kg gross. Fits 15 to 32 inch displays14.0 kg weight capacity270° pivot, -90° to +90° tiltSwivel 90° / 90°VESA 75 x 75 mm and 100 x 100 mmSteel and die-cast aluminium
In stock, ships immediately · delivery 1-2 days
WMK-01 is a two-piece wall mount kit made from high-grade steel with an electronic surface finish, installed quickly and with little space taken up. VESA patterns of 75 x 75 and 100 x 100 mm are supported for displays from 15 to 32 inches weighing up to 18.0 kg. Its weather-resistant construction is intended for indoor and outdoor environments such as retail, healthcare, finance and public spaces where space is limited. The bracket is finished in black and weighs 0.36 kg net, supplied 20 pieces per carton and 1080 pieces per pallet. Two-piece steel wall mount kit18.0 kg capacity, displays from 15 to 32 inchesVESA 75 x 75 and 100 x 100 mmElectronic surface finish, blackNet weight 0.36 kg20 pieces per carton, 1080 per pallet
Not in stock · delivery 3-4 days
Rated for 60.0 kg, the WMK-03 holds professional displays securely. Its free-angle tilt from -15 to 0 degrees saves space and allows the screen to be matched to the viewing direction at the installation site. VESA patterns of 100 x 100, 200 x 100 and 200 x 200 mm are supported for displays from 15 to 48 inches. The mount is made of steel with an electronic coating in black and measures 248.0 x 230.0 x 45.0 mm when assembled. Net weight is 2.2 kg, with ten pieces per carton and 420 pieces per pallet. 60.0 kg weight capacityTilt range -15 to 0 degreesFits displays from 15 to 48 inchesVESA 100 x 100, 200 x 100 and 200 x 200 mmSteel with electronic coating, black2.2 kg net weight, ten pieces per carton
In stock, ships immediately · delivery 1-2 days
Product data
- Manufacturer
- AG-Neovo
- Article number
- TX-2202A
- EAN / GTIN
- 4710739597288
Description
The TX-2202A pairs a 21.5-inch panel at Full HD resolution, 1920 x 1080 pixels in 16:9, with a projected capacitive touch layer that registers ten points. Image characteristics include a 1000:1 contrast ratio, 250 cd/m² brightness, 16.7 million colours, 178/178 degree viewing angles and flicker-free output. IP65 sealing protects the front, and the metal casing ships with a height adjustable stand and an integrated speaker. Audio, DisplayPort, HDMI, VGA and USB Type-B form the input set, with RJ11 for external control. Glass thickness is 2.05 mm, operation is rated from 0 °C to 40 °C at 20 to 80 percent non-condensing humidity, and frequency ranges run 30 to 84 kHz horizontally and 50 to 76 Hz vertically. PMK-01, WMK-01 and WMK-03 cover wall mounting.
- 10-point PCAP touch, 21.5-inch panel
- Full HD 1920 x 1080 (16:9), 250 cd/m²
- 1000:1 contrast, 178/178 viewing angles
- Front-sided IP65 rating
- Height adjustable stand and speaker
- Audio, DisplayPort, HDMI, VGA, USB Type-B
Made by
AG Neovo builds displays for continuous operation: surveillance monitors with 24/7 rating, metal housing and burn-in protection from 10 to 55 inches, public view monitors with a built-in camera, stretched displays for video walls, 4K digital signage, interactive smartboards with AI camera, plus workstations and mounts. Every model comes with technical data, data sheet, manual and certificates. AI4Vision is an authorised distributor; trade prices after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
- Aspect Ratio
- 16:9
- Audio In
- Stereo Audio Jack (3.5 mm)
- Brightness
- 250 cd/m², < 350 cd/㎡
- Casing Colour
- White
- Colour Gamut
- NTSC 72%
- Contrast Ratio
- 1000:1
- Diagonal Sizes
- 22"-28"
- Display Colour
- 16.7M
- DisplayPort
- x 1
- External Control
- RJ11
- Features
- HAS (Height Adjustable Stand), IP Rating, Speaker
- Frequency (H)
- 30 kHz-84 kHz
- Frequency (V)
- 50 Hz-76 Hz
- HDMI
- 1.4 x 1
- Humidity
- 10%-90% (non-condensing), 20%-80% (non-condensing)
- IK Rating
- IK07
- IP Rating
- Front-Sided IP65
- Innovation
- Metal Casing
- Inputs
- Audio, DisplayPort, HDMI, RJ11, USB Type-B, VGA
- MOHS Hardness
- 5
- Max. Resolution
- FHD 1920 x 1080
- Multi-touch Plug & Play
- 10-point touch for Windows® 7/8/10/11 Linux/Android 2.6.32 or Later Mac OS 10.11-10.14
- On Mode
- 15W(On)
- Operating Time (Internal)
- 24/7
- Orientation
- Landscape / Portrait
- Packaging
- 9.8 kg (21.6 lb)
- Packaging (W x H x D)
- 610.0 x 460.0 x 320.0 mm (24.0" x 18.1" x 12.6")
- Panel Interface
- USB (Type-B)
- Panel Size
- 21.5"
- Panel Size on Carton
- 21.5"
- Panel Type
- VA
- Pixel Pitch
- 0.248 mm
- Positional Accuracy
- ± 2.5 mm
- Power Adaptor Certifications
- CE,UKCA, BSMI,CB, CCC, EAC, WEEE, cUL, KCC, RCM, PSE, NOM, CSA, VCCI, PSB
- Power Requirements
- DC 12V, 4A
- Power Supply
- External
- Product w/o Base
- 4.8 kg (10.6 lb)
- Product w/o Base (W x H x D)
- 528.6 x 324.3 x 48.5 mm (20.8" x 12.8" x 1.9")
- Product with Base
- 6.7 kg (14.8 lb)
- Product with Base (W x H x D)
- 528.6 x 346.7 x 214.2 mm (20.8" x 13.7" x 8.4")
- RJ11
- Yes
- Rear Cover Material
- Metal
- Resolution
- FHD 1920 x 1080 (16:9)
- Response Time
- 5 ms
- Single Touch Support by Driver
- 1 point touch for Windows XP/Embedded/7/8/10/11 Linux/Android 2.6.31 and older
- Standby Mode
- < 0.7W
- Supplied
- Audio Cable, HDMI Cable, Power Adaptor, Power Cord, Quick Start Guide, USB Cable, VGA Cable
- Surface Treatment
- Anti-Glare Treatment (Haze 25%), 3H Hard Coating, Clear Glass
- Technology
- Projective Capacitive
- Temperature
- -20°C-60°C (-4°F-140°F), 0°C-40°C (32°F-104°F)
- Thickness
- 2.05 mm (0.08")
- Tilt
- -5° to 90°
- Touch Technology
- PCAP
- VGA
- 15-Pin D-Sub x 1
- Viewing Angle (H/V)
- 178°/178°
- Viewing Angles
- 178/178
- Visibility
- Flicker-Free
- Wall Mount
- PMK-01, WMK-01, WMK-03
