Professional AC24V (DC24V Optional) Cast Camera Housing
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 2-3 weeks
Product data
- Manufacturer
- AETEK
- Article number
- P2000-I
- EAN / GTIN
- 4711502640880
Description
Cast aluminium camera housing to IP68 and IK10, laid out for box cameras with wide-angle and long lenses from 8 to 80 mm. A window heater and a blower keep the glass clear of mist and ice: the heater comes on at 20 °C or below and drops out from 30 °C, the blower starts from 35 °C and stops at 25 °C or below. Supply 24 V AC, 24 V DC optional, with an output budget of 30 W at 12 V DC and 80 W at 24 V AC. The working range is -20 °C to 65 °C, or -20 °C to 50 °C with IR illuminators; the camera fitted inside must be cleared for -20 °C to 65 °C. Also on board: an adjustable sunshield, a side-opening alarm switch, an ITB board that takes an IR illuminator with no visible wiring, one RS485 port and an input and output for IR control and status. 502.8 x 170 x 158.5 mm, 2.8 kg, four M16 glands.
Made by
AETEK builds PoE switches for video security installations: from compact 4-port units to 24-port switches, with PoE+ and PoE++/bt, as desktop, rack and ceiling units with daisy-chain capability, also for outdoors with fibre uplinks. For selection, look at total PoE budget, port count, SFP uplinks and temperature range. Technical data and data sheets on every article, trade prices after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Electrical Specifications (3)
- AC24V Output Power Budget
- 80W
- DC12V Output Power Budget
- 30W
- Electrical Specifications – Input Voltage
- AC24V (DC24V Optional)
Environmental Specifications (5)
- DI Ports
- DI 1 for IR control
- DO Ports
- DO 1 for IR LED status
- Environmental Specifications – Operating Temperature -20°C ~ 65°C (-4°F ~ 149°F) -20°C ~ 50°C (w/IR LEDs) * Inside camera specifications must be within -20°C ~ 65°C Window Heater ON / OFF ≤ 20°C (68°F) ON ≥ 30°C (86°F) OFF Blower ON / OFF ≥ 35°C (95°F) ON
- IP68
- Environmental Specifications – Vandal Proof
- IK10 Impact Rated on Cast Aluminum Housing
- RS485 Ports
- 1
Mechanical Specifications (4)
- Body Material
- Cast Aluminum
- Body Weight
- 2.8 kg (6.17 lb)
- Cable Grants
- M16 x 4
- Mechanical Specifications – Dimensions (L x W x H)
- 502.8 x 170 x 158.5 mm
