Medium IP POE IR LED Illuminator
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 3-4 days
Matching accessories
The SECL-BRCKT-WALL-1 is a wall bracket for a single illuminator. It allows rotation of up to 180 degrees. Alignment is fully adjustable to the left, right, up and down. The bracket is made of stainless steel with a black powder-coated finish. Wall bracket for one illuminatorRotation up to 180 degreesAdjustable left, right, up and downStainless steel, black powder-coated
Not in stock · delivery 3-4 days
The SECL-BRCKT-WALL-2 is a wall bracket for two illuminators and therefore doubles the angle of illumination. Where two equivalent illuminators are used, the illumination distance increases by a factor of 1.4. Illuminators with different angles and distances can be combined, and hybrid models also allow infrared and white light units to be mixed. The bracket adjusts to the left, right, up and down and is made of black powder-coated stainless steel. An IP67 rated junction box is included. Wall bracket for two illuminatorsDoubles the angle of illumination1.4x distance with two equivalent illuminatorsMixes infrared and white light on hybrid modelsIP67 rated junction box includedStainless steel, black powder-coated
Not in stock · delivery 3-4 days
The SECL-BRCKT-WALL-3 is a wall bracket for three illuminators and triples the angle of illumination. With three equivalent illuminators the illumination distance rises by a factor of 1.7. Units with different angles and distances can be mixed, and hybrid models also permit infrared and white light to be combined. Alignment to the left, right, up and down is possible, and the bracket is made of black powder-coated stainless steel. An IP67 rated junction box forms part of the delivery. Wall bracket for three illuminatorsTriples the angle of illumination1.7x distance with three equivalent illuminatorsMixes infrared and white light on hybrid modelsIP67 rated junction box includedStainless steel, black powder-coated
Not in stock · delivery 3-4 days
Product data
- Manufacturer
- Hanwha Vision
- Article number
- SECL-IR850-IPPOEPL-M
- EAN / GTIN
- 8801089218001
- Weight
- 1.76 kg
- Dimensions (W×H×D)
- 205 × 170 × 220 mm
Description
The SECL-IR850-IPPOEPL-M is a medium size IP infrared illuminator powered over PoE. It uses semi covert 850nm IR LEDs, for which the manufacturer states consistent illumination and a projected working life of more than ten years. Under difficult lighting conditions the unit improves image quality and analytics; box type cameras are named as a typical pairing. An integrated photocell sensor with adjustable sensitivity handles automatic switching, while a vibration sensor with programmable triggers protects the device. Interchangeable diffuser lenses provide different distance and field of view profiles, and the illuminator is intended for indoor and outdoor installations.
- Medium IP IR illuminator with PoE
- Semi covert 850nm IR LEDs
- Projected LED life over ten years
- Photocell sensor with adjustable sensitivity
- Vibration sensor with programmable triggers
- Interchangeable diffuser lenses
Made by
Hanwha Vision (formerly Hanwha Techwin, the Wisenet brand) is the largest manufacturer in the AI4Vision catalogue: dome, bullet, PTZ, fisheye, multi-sensor and thermal cameras, network recorders, the Wisenet WAVE video management system, encoders and decoders, monitors, IP audio, intercom and access controllers, plus mounts and housings. The P and X series cameras carry AI video analytics on board. As an authorised distributor, AI4Vision carries the Wisenet range with technical data and manufacturer data sheets; trade partners see prices and availability after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
