Industrial Gigabit Media Converter
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 2-3 weeks
Product data
- Manufacturer
- AETEK
- Article number
- M30-022-01
- EAN / GTIN
- 4711502641313
Description
Media converter with four Gigabit ports: two 10/100/1000BASE-T copper connections and two SFP slots for 100/1000BASE-X. Two runs can change to fibre at one point without a second unit. Power 12 to 56 V DC, standby draw 1 W at 48 V DC, DIN-rail mounting, IP30 case, no fan. Working range -40 °C to 75 °C, storage to 85 °C, humidity 5 to 95 % non-condensing. Switching capacity 8 Gbps, forwarding 5.592 Mpps, 4K MAC table, jumbo frames 9K bytes, Energy Efficient Ethernet to IEEE 802.3az. Surge protection 6 kV common mode, ESD ±4 kV on contact. 87 x 33 x 120 mm, 0.19 kg.
Made by
AETEK builds PoE switches for video security installations: from compact 4-port units to 24-port switches, with PoE+ and PoE++/bt, as desktop, rack and ceiling units with daisy-chain capability, also for outdoors with fibre uplinks. For selection, look at total PoE budget, port count, SFP uplinks and temperature range. Technical data and data sheets on every article, trade prices after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Environmental limits (4)
- Environmental limits IP Rating
- IP30
- Environmental limits – Operating Humidity
- 5% to 95% non-condensing
- Environmental limits – Operating Temperature
- -40°C ~ 75°C (-40°F ~ 167°F)
- Environmental limits – Storage Temperature
- -40°C ~ 85°C (-40°F ~ 185°F)
Mechanical (4)
- Cooling Fan
- Fanless
- Dimensions (W x D x H)
- 87 x 33 x 120 mm (3.4 x 1.3 x 4.7 in)
- Mechanical Mounting
- Din-Rail
- Mechanical Weight
- 0.19 kg (0.42 lb)
Networking (7)
- Gigabit Ethernet RJ45 Ports
- 1
- Networking Forwarding Capacity
- 5.592 Mpps
- Networking Jumbo Frames
- 9K Bytes
- Networking Mac Table
- 4K
- Networking Switching Capacity
- 8 Gbps
- Networking – Gigabit Ethernet SFP Ports (100M/1G)
- 2
- Networking – Total Gigabit Ethernet Ports
- 4
Power (6)
- ESD
- Contact ±4 KV, Air ±8 KV
- Power Input Voltage
- 12V-56V DC
- Power – Surge Protection for DC Power Input
- Differential mode : ±1 KV
- Power – Surge Protection for DC Power Output
- Differential mode : ±1 KV
- Standby Power Consumption
- 48V DC: 1W
- Surge Protection per PoE Port
- Common mode : ±6 KV
Regulatory/ Approvals (3)
- Regulatory/ Approvals EMC
- CE, FCC, VCCI, C-Tick
- Regulatory/ Approvals MTBF
- > 50000 hours
- Regulatory/ Approvals Surge
- EN61000-4-5
