IP Microphone
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 3-4 days
Product data
- Manufacturer
- Hanwha Vision
- Article number
- SPA-M2000
- EAN / GTIN
- 8801089231628
- Weight
- 2.32 kg
- Dimensions (W×H×D)
- 710 × 531 × 235 mm
Description
The SPA-M2000 is a SIP microphone for IP audio systems, connected to the network over 10/100 Base-T. Its embedded microphone has an input sensitivity of -50 dBV within 3 dB at maximum mic volume and covers 100 Hz to 6 kHz, while the line input accepts up to -7 dBV at maximum aux input volume. A monitor amplifier rated 1 W into 8 ohm is integrated. Supported protocols are IPv4, HTTP, HTTPS, SIP, mDNS, DNS, NTP, TCP, UDP, DHCP, ARP and ICMP, and integration is handled through SUNAPI as an HTTP API with connection verification and built-in system logging. Access is protected by passwords for admin, setup, user and guest with SHA-2 and digest authentication, and the VoIP function has been tested with SIP clients such as Grandstream, Yealink, Cisco and MicroSIP as well as PBX systems such as Asterisk. Power is PoE per IEEE 802.3af Type 1 Class 3 or DC24V at up to 12 W. The black housing measures 200 x 73 x 206 mm, weighs 1.3 kg and is rated from -10 to +40 C.
- SIP microphone for IP audio
- Frequency response 100 Hz to 6 kHz
- Monitor amplifier 1 W into 8 ohm
- PoE 802.3af or DC24V, max. 12 W
- SUNAPI HTTP API
- 10/100 Base-T network
Made by
Hanwha Vision (formerly Hanwha Techwin, the Wisenet brand) is the largest manufacturer in the AI4Vision catalogue: dome, bullet, PTZ, fisheye, multi-sensor and thermal cameras, network recorders, the Wisenet WAVE video management system, encoders and decoders, monitors, IP audio, intercom and access controllers, plus mounts and housings. The P and X series cameras carry AI video analytics on board. As an authorised distributor, AI4Vision carries the Wisenet range with technical data and manufacturer data sheets; trade partners see prices and availability after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Amplifier (1)
- Description
- 1W/8Ω, Monitor Amp
Embeded MIC (2)
- Embeded MIC Frequency Response
- 100Hz~6kHz
- Input Sensitivity
- -50 dBV± 3 dB (Mic Volume Max)
General (7)
- Certificate
- EMC : KS C 9832/9835, EN 55.32/55035, FCC Part 15 Subpart B, ICES-003, Safety : KC 62368-1, UL 62368-1, CAN/CSA 62368-1
- General Color
- Black
- General Operating Humidity
- 10~85%RH(Non-Condensing)
- General Operating Temperature
- -10°~+40°C(-14°F~+104°F)
- General Weight
- 1.3 Kg (2.87lb)
- IP Code
- N/A
- Size
- 200(W) x 73(H) x 206(L)mm
Line Input (1)
- Maximum Input Level
- -7 dBV, Aux Input Volume Max
Network (1)
- Network – Ethernet
- 10/100 Base-T
Network Protocol (2)
- Network Protocol Security
- Password protection : admin, setup, user, guest (sha-2, Digest authentication, User access log), Digest authentication, User access log
- Network Protocol – Supported Protocols
- IPv4, HTTP, HTTPS, SIP, mDNS, DNS, NTP, TCP, UDP, DHCP, ARP, ICMP
Power (2)
- Power PoE
- PoE (IEEE 802.3 af type 1 Class 3)
- Power – Power
- DC24V, Max 12W
Product (1)
- IP Audio Type
- IP Microphone
System Integration (3)
- Functional Monitoring
- Connection verification, Built-in system logging
- System Integration – Application Programming Interface
- SUNAPI(HTTP API)
- VoIP
- Tested with SIP clients such as Grandstream, Yealink, Cisco, MicroSIP softphone and PBX supplier such as Asterisk, Supported SIP features : DTMF (RFC2833), Supported codecs : PCMU, PCMA, speex/8000, speex/16000
