IP Horn Speaker
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 3-4 days
Product data
- Manufacturer
- Hanwha Vision
- Article number
- SPA-H100W
- EAN / GTIN
- 8801089187444
- Weight
- 4.73 kg
- Dimensions (W×H×D)
- 335 × 410 × 265 mm
Description
The SPA-H100W is an IP horn speaker in white rated IP66 for outdoor and industrial use. Amplification comes from a built-in 10 W Class D stage and the network side runs on 10/100 Base-T. The frequency range at -10 dB spans 650 Hz to 5.3 kHz, sensitivity is 111 dB at 1 watt, and maximum sound pressure level is stated as 121 dB on PoE and 124 dB on PoE+, produced by a 1-inch dome type HF driver. Announcements are held in 1 GByte of internal memory, with WAV and MP3 in mono or stereo from 64 to 320 kbps at sampling rates of 16 kHz to 48 kHz, and text-to-speech is available in English (US and UK), German, French, Spanish and Russian. Supported protocols are IPv4, HTTP, SIP, mDNS, DNS, NTP, TCP, UDP, DHCP, ARP and ICMP, complemented by one dry contact input and one dry contact output. Power is PoE per IEEE 802.3af Type 1 Class 3 or PoE+ per IEEE 802.3at Type 2 Class 4; the housing measures 241 x 155 x 307 mm, weighs 3.7 kg and operates from -40 to +55 C with cold start from -35 C.
- IP66 rated
- Built-in 10 W Class D amplifier
- Sensitivity 111 dB at 1 watt
- Max. SPL 121 dB on PoE, 124 dB on PoE+
- Frequency range 650 Hz to 5.3 kHz
- Operation from -40 to +55 C
Made by
Hanwha Vision (formerly Hanwha Techwin, the Wisenet brand) is the largest manufacturer in the AI4Vision catalogue: dome, bullet, PTZ, fisheye, multi-sensor and thermal cameras, network recorders, the Wisenet WAVE video management system, encoders and decoders, monitors, IP audio, intercom and access controllers, plus mounts and housings. The P and X series cameras carry AI video analytics on board. As an authorised distributor, AI4Vision carries the Wisenet range with technical data and manufacturer data sheets; trade partners see prices and availability after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Amplifier (1)
- Description
- Built in 10W Class D
Audio (1)
- Supported Audio Format
- WAV, MP3 in mono/stereo from 64 kbps to 320 kbps. Sampling rate from 16kHz up to 48 kHz
Contact (2)
- Contact Input. Dry contact
- One Channel
- Contact Output. Dry contact
- One channel
Embeded MIC (2)
- Embeded MIC Frequency Response
- Sound Level Meter
- Input Sensitivity
- Sound Level Meter
General (7)
- Certificate
- EMC : KS C 9832/9835, EN 55.32/55035, FCC Part 15 Subpart B, ICES-003, Safety : UL 62368-1, CAN/CSA 62368-1
- General Color
- White
- General Operating Humidity
- 10~85%RH(Non-Condensing)
- General Operating Temperature
- -40°C~+55°C(-40°F~+131°F) (Cold start : -35°C/-31°F)
- General Weight
- 3.7Kg (8.16lb)
- IP Code
- IP66
- Size
- 241(W) x 155(H) x 307(D)mm
Memory (1)
- Internal Memory
- 1 GBytes
Network (1)
- Network – Ethernet
- 10/100 Base-T
Network Protocol (2)
- Network Protocol Security
- Password protection : admin, setup, user, guest (sha-2, Digest authentication, User access log)
- Network Protocol – Supported Protocols
- IPv4, HTTP, SIP, mDNS, DNS, NTP, TCP, UDP, DHCP, ARP, ICMP
Power (3)
- PoE+
- (IEEE 802.3 at type 2 Class 4)
- Power PoE
- PoE (IEEE 802.3 af type 1 Class 3)
- Power – Power
- N/A
Product (1)
- IP Audio Type
- IP Horn Speaker
Speaker (6)
- Coverage Pattern
- (HxV) : 130° X 160° (1 kHz) / 30° X 50°(1 kHz)
- Frequency Range (-10 dB)
- 650 Hz ~ 5.3 kHz
- Max. Sound Pressure Level
- 121 dB
- Sensitivity (1 Watt)
- 111 dB
- Speaker Component
- 1" HF Driver. Dome type
- Speaker – Max. Sound Pressure Level (PoE+)
- 124 dB
System Integration (7)
- Audio Monitoring
- Speaker test by graphic level meter (Built in test tool)
- Event & Preset
- Virtual Contact, Dry contact
- Functional Monitoring
- Connection verification, Built-in system logging
- System Integration – Application Programming Interface
- SUNAPI(HTTP API), ONVIF Profile S
- System Integration – Multi-source Dynamic PA control
- Multi-source up to 48 (Multicast) (Audio 24CH + Mic 24CH) (Up to 15 audio channels can be broadcast simultaneously), Up to 256 Zone Control (Multicast), Up to 20 Zone Control (Unicast), Up to 255 Groups
- TTS
- English (US, UK), German, French, Spanish, Russian
- VoIP
- Tested with SIP clients such as Grandstream, Yealink, Cisco, MicroSIP softphone and PBX supplier such as Asterisk, Supported SIP features : DTMF (RFC2833), Supported codecs : PCMU, PCMA, speex/8000, speex/16000
