IP Audio Bridge
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 3-4 days
Product data
- Manufacturer
- Hanwha Vision
- Article number
- SPA-B1000
- EAN / GTIN
- 8801089186232
- Weight
- 0.4 kg
- Dimensions (W×H×D)
- 180 × 145 × 50 mm
Description
The SPA-B1000 is an IP audio module that bridges analogue audio sources into an IP network. Its line input accepts a maximum of +6 dBV on left and right, amplification is handled by a built-in 10 W Class D stage, and the network side uses 10/100 Base-T. Announcements can be stored in 1 GByte of internal memory or on a micro SD card, SDHC up to 32 GB (SANDISK), with WAV and MP3 in mono or stereo from 64 to 320 kbps and sampling rates from 16 kHz to 48 kHz. One dry contact input and one dry contact output are provided, and integration runs over SUNAPI as an HTTP API with connection verification and built-in system logging. Supported protocols are IPv4, HTTP, HTTPS, mDNS, DNS, NTP, TCP, UDP, DHCP, ARP and ICMP, protected by passwords for admin, setup, user and guest using SHA-2, digest authentication and a user access log. Power is PoE per IEEE 802.3af Type 1 Class 3 at up to 10 W, or DC24V. The white housing measures 123 x 80 x 30.6 mm, weighs 0.24 kg and works from -20 to +50 C at 10 to 95 percent non-condensing humidity.
- Built-in 10 W Class D amplifier
- 1 GByte internal memory
- Micro SD up to 32 GB SDHC
- PoE IEEE 802.3af or DC24V
- One dry contact input and output
- SUNAPI HTTP API
Made by
Hanwha Vision (formerly Hanwha Techwin, the Wisenet brand) is the largest manufacturer in the AI4Vision catalogue: dome, bullet, PTZ, fisheye, multi-sensor and thermal cameras, network recorders, the Wisenet WAVE video management system, encoders and decoders, monitors, IP audio, intercom and access controllers, plus mounts and housings. The P and X series cameras carry AI video analytics on board. As an authorised distributor, AI4Vision carries the Wisenet range with technical data and manufacturer data sheets; trade partners see prices and availability after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Amplifier (1)
- Description
- Built in 10W Class D
Contact (2)
- Contact Input. Dry contact
- One Channel
- Contact Output. Dry contact
- One channel
General (7)
- Certificate
- EMC : KS C 9832/9835, EN 55.32/55035, FCC Part 15 Subpart B, ICES-003, Safety : UL 62368-1, CAN/CSA 62368-1
- General Color
- White
- General Operating Humidity
- 10~95%RH(Non-Condensing)
- General Operating Temperature
- -20°~+50°C(-4°F~+122°F)
- General Weight
- 0.24Kg (0.53lb)
- IP Code
- N/A
- Size
- 123(W)*80(H)*30.6(W)mm
Line Input (1)
- Maximum Input Level
- L, R : +6 dBV Max
Memory (2)
- External Memory (Micro SD)
- SDHC upto 32GB (SANDISK)
- Internal Memory
- 1 GBytes
Network (1)
- Network – Ethernet
- 10/100 Base-T
Network Protocol (2)
- Network Protocol Security
- Password protection : admin, setup, user, guest (sha-2, Digest authentication, User access log)
- Network Protocol – Supported Protocols
- IPv4, HTTP, HTTPS, mDNS, DNS, NTP, TCP, UDP, DHCP, ARP, ICMP
Power (2)
- Power PoE
- PoE (IEEE 802.3 af type 1 Class 3), Max.10W, DC24V
- Power – Power
- N/A
Product (1)
- IP Audio Type
- IP Audio Module
System Integration (3)
- Event & Preset
- Virtual Contact, Dry contact
- Functional Monitoring
- Connection verification, Built-in system logging
- System Integration – Application Programming Interface
- SUNAPI(HTTP API)
