EPoC RX Switch
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 2-3 weeks
Product data
- Manufacturer
- AETEK
- Article number
- XC10-041-250
- EAN / GTIN
- 4711502640606
Description
EPoC receive switch for the head end of a coaxial run: four 75 Ω BNC ports and one Gigabit RJ45 port, plus a built-in 250 W supply for 100 to 240 VAC. Working in RX mode, it carries data and PoE onward over existing RG6 coax – at 1,200 m the camera still gets 9.7 W, whatever brand it is. That lets older RG59 or RG6 CCTV cabling be moved to IP without pulling new cable, and unlike fibre the coax delivers the camera's power as well. Every coax port has 6 kV surge protection, and the unit also accepts 56 VDC as a back-up feed. Brackets for a 19-inch rack are included. Size 276.6 x 178 x 44 mm, weight 1 kg, operating range -10 °C to 50 °C, EN60950-1.
Made by
AETEK builds PoE switches for video security installations: from compact 4-port units to 24-port switches, with PoE+ and PoE++/bt, as desktop, rack and ceiling units with daisy-chain capability, also for outdoors with fibre uplinks. For selection, look at total PoE budget, port count, SFP uplinks and temperature range. Technical data and data sheets on every article, trade prices after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Certifications (2)
- Certifications EMC
- CE, FCC, VCCI, C-Tick
- Safety
- EN60950-1
Environmental Specifications (3)
- Environmental Specifications – Operating Humidity
- 5% ~ 95% non-condensing
- Environmental Specifications – Operating Temperature
- -10°C ~ 50°C (14°F ~ 122°F)
- Environmental Specifications – Storage Temperature
- -20°C ~ 85°C (-28°F ~ 185°F)
Interface (4)
- Distance 75Ω Coaxial BNC Port
- 4
- Distance MAX. Distance
- 9.7W@1200m(3937 ft)
- Distance Transmission mode
- RX mode
- Interface / Distance – 10/100/1000Mpps Ethernet RJ45 Port
- 1
Mechanical Specifications (3)
- Mechanical Specifications – Connectors
- BNCx4, RJ45x1, 100-240VAC power input, 56VDC input
- Mechanical Specifications – Dimensions (L x W x H)
- 276.6 x 178 x 44 mm (10.89x7x1.73")
- Mechanical Specifications – Weight
- 1 kg (2.20 lb)
PoE Specifications (5)
- Back-up Power Input Voltage
- 56VDC
- PoE PD
- -
- PoE Specifications – PoE Pass Through
- v
- PoE Specifications – Power supply
- Input: 100-240VAC 280VAC 4hr 300VAC 1min.
- PoE Specifications – Surge Protection /each Coax Port
- Built-in 6KV
