Controller
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 3-4 days
Product data
- Manufacturer
- Hanwha Vision
- Article number
- SPC-2001
- EAN / GTIN
- 8801089219862
- Weight
- 0.7 kg
- Dimensions (W×H×D)
- 256 × 238 × 143 mm
Description
The SPC-2001 is a joystick controller connected through a 4-pin USB Type A port and running on standard DirectX drivers (DirectInput). Its 3-axis joystick uses the Hall-effect principle, travelling -28° to +28° on the X and Y axes and -23.5° to +23.5° on the Z axis, with two springs in two directions handling the return to centre. Twelve buttons are additionally available, and actuation forces are 0.109 [N·m] minimum, 0.151 [N·m] operating and 0.169 [N·m] maximum. The housing is ABS, the handle polycarbonate, the button cover rubber and the shaft SUM24L with Ni plating; the 2 [m] cable supplies 5 [V] DC (±0.5 [V]) and 50 [mA] over USB. The black unit measures 182x182x106mm at 405g and is specified for 0℃ to +40℃ at 20% to 85% RH. According to the manufacturer there is system compatibility with CMS software on the PC (SSM, Wisenet Viewer).
- USB joystick controller, 4-pin Type A port
- Hall-effect 3-axis joystick
- 12 buttons, 2 [m] cable
- Range of movement -28° to +28° on X and Y
- Dimensions 182x182x106mm, 405g
- Standard DirectX drivers (DirectInput)
Made by
Hanwha Vision (formerly Hanwha Techwin, the Wisenet brand) is the largest manufacturer in the AI4Vision catalogue: dome, bullet, PTZ, fisheye, multi-sensor and thermal cameras, network recorders, the Wisenet WAVE video management system, encoders and decoders, monitors, IP audio, intercom and access controllers, plus mounts and housings. The P and X series cameras carry AI video analytics on board. As an authorised distributor, AI4Vision carries the Wisenet range with technical data and manufacturer data sheets; trade partners see prices and availability after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Communication (1)
- Communication Interface
- 4-pin USB Type A Port
Electrical (2)
- Electrical Operating Voltage
- (DC 5 [V]), Vdd = 5 [V] (±0.5 [V]) via USB
- Operating Current
- 50 [mA]
Environmental (1)
- Environmental – Operating Temperature
- 0℃ to +40℃ (20% ~ 85% RH)
Materials (6)
- Cover
- Rubber (Button)
- Materials Cable Length
- 2 [m]
- Materials Color
- Black
- Materials Handle
- Poly Carbonate
- Materials Housing
- ABS
- Shaft
- SUM24L + Ni plating
Mechanical (2)
- Mechanical Dimensions (WxhxD)
- 182x182x106mm
- Mechanical Weight
- 405g
Operational (2)
- Button
- 12ea
- Operational Joystick
- Hall-effect 3 Axis
Performance (6)
- Center
- Two Spring, Two Directions
- Maximum Power
- 0.169 [N·m]
- Minimum Power
- 0.109 [N·m]
- Operating Power
- 0.151 [N·m]
- Range of Movement X/Y-Axis
- -28° ~ +28°
- Range of Movement Z Axis
- -23.5° ~ +23.5°
Software (1)
- Drivers
- Standard DirectX Drivers (DirectInput)
