Ajax TurretCam HLVF (5MP) black
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 2-3 days
Matching accessories
The Ajax MountCam A2 in black serves as a universal camera bracket with a sturdy black aluminium frame. Ajax cameras can be mounted on it, and rotation through 360° is possible. The manufacturer names straightforward installation. The bracket is designed to resist weather influences and is modern in appearance. A secure camera overview is supported in this way. Universal camera bracketSturdy black aluminium frameCompatible with Ajax cameras360° rotationWeather resistant
Not in stock · delivery 2-3 days
The Ajax MountCam B2 universal camera bracket comes with a sturdy black aluminium frame. Ajax cameras can be mounted on it, and rotation through 360° is provided for. The manufacturer names straightforward installation. The bracket is designed to resist weather influences and is modern in appearance. It supports a secure camera overview. Universal camera bracketSturdy black aluminium frameCompatible with Ajax cameras360° rotationWeather resistant
Not in stock · delivery 2-3 days
Product data
- Manufacturer
- Ajax
- Article number
- 126280.197.BL1
- EAN / GTIN
- 4823114087073
Description
The Ajax TurretCam HLVF is a wired AI-powered IP camera with a motorized 2.8–12.0 mm varifocal lens, a fixed f/1.6 aperture and hybrid illumination. Its 5 MP CMOS sensor of the 1/2.7" type covers 31–111° horizontally, 17–57° vertically and 35–135° diagonally, while the white LED lights up to 40 m and the IR LED up to 60 m. Colour capture begins at 0.005 lx and black-and-white extends to 0 lx, at more than 52 dB signal-to-noise ratio and 120 dB dynamic range (True WDR). Video is recorded at up to 25 fps in H.265 or H.264 to microSD at 5 MP (2880 × 1620), 4 MP (2560 × 1440), 3 MP (2304 × 1296), 2 MP (1920 × 1080) or 0.6 MP (1024 × 576), with image rotation of 0°, 90°, 180° or 270°. A microphone is built in, audio uses G.711 µ-law, G.711 A-law, G.726 and G.722, and the alarm port carries 2 lines for third-party devices. AI object detection covers people, pets, vehicles and line-crossing, and connection is via one RJ45 self-adaptive Ethernet port (10/100 Mbps) with HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, DHCP and DNS, conformant with ONVIF® Profile S.
- Motorized 2.8–12.0 mm varifocal lens at f/1.6
- 5 MP CMOS 1/2.7" type, 35–135° diagonal field of view
- White LED up to 40 m, IR LED up to 60 m
- Up to 25 fps, 120 dB True WDR, microSD recording
- Built-in microphone, alarm port with 2 lines
- AI object detection incl. line-crossing, ONVIF® Profile S
Made by
Ajax Systems is the alarm and security system with the widest range in the catalogue: hubs, motion, opening and glass break detectors, MotionCam with photo verification, sirens, keypads, the EN54 fire detection line, cameras, the Ajax NVR and automation and comfort devices – as the Jeweller wireless system or wired via Fibra, in white and black. The Superior line is certified to EN 50131 Grade 3. AI4Vision is an authorised Ajax partner. All devices are managed through the Ajax app and the monitoring station connection; trade partners see prices and availability after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Additional information (1)
- Additional information – Warranty
- 24 months
Alarm port (3)
- Alarm port – Alarm IN type
- NO, NC
- Alarm port – Alarm OUT operating range
- 24 V⎓, 300 mA
- Alarm port – Lines for third-party devices
- 2
Audio (2)
- Audio – Audio codec
- G.711 µ-law, G.711 A-law, G.726, G.722
- Audio – Built-in microphone
- 1
Audio port (4)
- Audio port – Audio IN settings
- gain, enable/disable
- Audio port – Audio IN type
- external microphone input
- Audio port – Audio OUT type
- speaker output
- Audio port – Lines for third-party devices
- 2
Camera (9)
- Camera – Field of view
- horizontal: 31°–111°, vertical: 17°–57°, diagonal: 35°–135°
- Camera – Image sensor
- 5 MP CMOS, 1/2.7" type
- Camera – Lens focal length
- 2.8–12.0 mm
- Camera – Lens focal type
- varifocal
- Camera – Lens iris type
- fixed
- Camera – Maximum aperture
- f/1.6
- Camera – Maximum illumination distance
- white LED: up to 131 ft, IR LED: up to 196 ft
- Camera – Minimum illumination
- color: 0.005 lx, B/W: 0 lx
- Camera – Signal-to-noise ratio (SNR)
- more than 52 dB
Enclosure (5)
- Enclosure – Dimensions
- 5.35″ × 4.45″ × 5.35″
- Enclosure – Operating humidity
- up to 90%
- Enclosure – Operating temperature range
- from −40 °F to 140 °F
- Enclosure – Protection class
- IP67, IK10
- Enclosure – Weight
- 1.87 lb
Intelligent video analytics (1)
- Intelligent video analytics – AI object detection
- People, Pets, Vehicles, Line-crossing
Key features (2)
- Key features – Focal length change
- autofocus, manual focus control
- Key features – Video transmission
- JetSparrow
Network (3)
- Network – ONVIF®
- conformant with ONVIF® Profile S
- Network – Port
- 1 × RJ45 self-adaptive Ethernet (10/100 Mbps)
- Network – Protocol
- HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, DHCP, DNS
Power supply (4)
- Power supply – External power connector type
- screw terminal connector (2 pin)
- Power supply – PoE standard
- 802.3at/af (Class 3)
- Power supply – Power consumption
- maximum: up to 12 W, average: up to 6 W
- Power supply – Power supply unit
- 12 V⎓, 1 А
Sabotage protection (1)
- Sabotage protection – Authentication
- via Ajax Cloud
Video (6)
- Video – Dynamic range
- 120 dB (True WDR)
- Video – Frame rate
- up to 25 fps
- Video – Image rotation
- 0°, 90°, 180°, 270°
- Video – Resolution
- 5 MP (2880 × 1620), 4 MP (2560 × 1440), 3 MP (2304 × 1296), 2 MP (1920 × 1080), 0.6 MP (1024 × 576)
- Video – Storage
- microSD
- Video – Video codec
- H.265, H.264
