Ajax Superior BulletCam HLVF (4MP) black
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inIn stock, ships immediately · delivery 1-2 days
Matching accessories
The Ajax MountCam A2 in black serves as a universal camera bracket with a sturdy black aluminium frame. Ajax cameras can be mounted on it, and rotation through 360° is possible. The manufacturer names straightforward installation. The bracket is designed to resist weather influences and is modern in appearance. A secure camera overview is supported in this way. Universal camera bracketSturdy black aluminium frameCompatible with Ajax cameras360° rotationWeather resistant
Not in stock · delivery 2-3 days
The Ajax MountCam B2 universal camera bracket comes with a sturdy black aluminium frame. Ajax cameras can be mounted on it, and rotation through 360° is provided for. The manufacturer names straightforward installation. The bracket is designed to resist weather influences and is modern in appearance. It supports a secure camera overview. Universal camera bracketSturdy black aluminium frameCompatible with Ajax cameras360° rotationWeather resistant
Not in stock · delivery 2-3 days
Product data
- Manufacturer
- Ajax
- Article number
- 135569.217.BL1
- EAN / GTIN
- 4823114076381
Description
The Ajax Superior BulletCam HLVF is a wired outdoor IP camera built around a motorized varifocal lens with a P-Iris diaphragm. Its 4 MP CMOS sensor of the 1/1.8" type covers 2.8–12.0 mm focal length at a maximum aperture of f/1.4–2.3, giving a field of view of 47°–110° horizontally, 26°–56° vertically and 54°–135° diagonally, while hybrid illumination extends to 131 ft on the white LED and 196 ft on the IR LED. Video is captured at up to 25 fps in 4 MP (2688 × 1520), 3 MP (2304 × 1296), 2 MP (1920 × 1080) or 0.6 MP (1024 × 576), rotatable by 0°, 90°, 180° or 270°, encoded in H.265, H.264 or MJPEG with True WDR and stored on microSD or an Ajax NVR. Two built-in microphones and a 3 W speaker handle the G.711 µ-law, G.711 A-law, G.726 and G.722 codecs, and AI object detection reports People, Pets, Vehicles and Line-crossing. Connectivity runs through 1 × RJ45 self-adaptive Ethernet (10/100 Mbps) with HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, DHCP and DNS, conformant with ONVIF® Profile S, alongside 2 lines for third-party devices with NO or NC alarm IN type.
- 4 MP CMOS sensor, 1/1.8" type
- Motorized P-Iris varifocal lens 2.8–12.0 mm
- White LED up to 131 ft, IR LED up to 196 ft
- AI detection of people, pets and vehicles
- ONVIF® Profile S, RJ45 10/100 Mbps
Made by
Ajax Systems is the alarm and security system with the widest range in the catalogue: hubs, motion, opening and glass break detectors, MotionCam with photo verification, sirens, keypads, the EN54 fire detection line, cameras, the Ajax NVR and automation and comfort devices – as the Jeweller wireless system or wired via Fibra, in white and black. The Superior line is certified to EN 50131 Grade 3. AI4Vision is an authorised Ajax partner. All devices are managed through the Ajax app and the monitoring station connection; trade partners see prices and availability after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Additional information (1)
- Additional information – Warranty
- 24 months
Alarm port (3)
- Alarm port – Alarm IN type
- NO, NC
- Alarm port – Alarm OUT operating range
- 24 V⎓, 300 mA
- Alarm port – Lines for third-party devices
- 2
Audio (2)
- Audio – Audio codec
- G.711 µ-law, G.711 A-law, G.726, G.722
- Audio – Built-in microphones
- 2
Audio port (4)
- Audio port – Audio IN settings
- gain, enable/disable
- Audio port – Audio IN type
- external microphone input
- Audio port – Audio OUT type
- speaker output
- Audio port – Lines for third-party devices
- 2
Camera (7)
- Camera – Field of view
- horizontal: 47°–110°, vertical: 26°–56°, diagonal: 54°–135°
- Camera – Image sensor
- 4 MP CMOS, 1/1.8" type
- Camera – Lens focal length
- 2.8–12.0 mm
- Camera – Lens focal type
- varifocal
- Camera – Lens iris type
- P-Iris
- Camera – Maximum aperture
- f/1.4–2.3
- Camera – Maximum illumination distance
- white LED: up to 131 ft, IR LED: up to 196 ft
Enclosure (5)
- Enclosure – Dimensions
- 11.56″ × 5.35″ × 5.35″
- Enclosure – Operating humidity
- up to 90%
- Enclosure – Operating temperature range
- from −40 °F to 140 °F
- Enclosure – Protection class
- IP67, IK10
- Enclosure – Weight
- 3.307 lb
Intelligent video analytics (1)
- Intelligent video analytics – AI object detection
- People, Pets, Vehicles, Line-crossing
Key features (2)
- Key features – Focal length change
- autofocus, manual focus control
- Key features – Video transmission
- JetSparrow
Network (3)
- Network – ONVIF®
- conformant with ONVIF® Profile S
- Network – Port
- 1 × RJ45 self-adaptive Ethernet (10/100 Mbps)
- Network – Protocol
- HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, DHCP, DNS
Power supply (4)
- Power supply – External power connector type
- screw terminal connector (2 pin)
- Power supply – PoE standard
- 802.3at/af (Class 4)
- Power supply – Power consumption
- maximum: up to 12 W, average: up to 6 W
- Power supply – Power supply unit
- 12 V⎓ ±20%, 1.5 А
Sabotage protection (1)
- Sabotage protection – Authentication
- via Ajax Cloud
Speaker (1)
- Speaker – Output speaker power
- 3 W
Video (6)
- Video – Dynamic range
- True WDR
- Video – Frame rate
- up to 25 fps
- Video – Image rotation
- 0°, 90°, 180°, 270°
- Video – Resolution
- 4 MP (2688 × 1520), 3 MP (2304 × 1296), 2 MP (1920 × 1080), 0.6 MP (1024 × 576)
- Video – Storage
- microSD, Ajax NVR
- Video – Video codec
- H.265, H.264, MJPEG
