Ajax EN54 I/O Module (2X2) black

Name: Ajax EN54 I/O Module (2X2) black
Brand: Ajax
SKU: 124591.280.BL1

Ajax

Price after sign-in

Prices and conditions are shown once you sign in with your customer account.

Not in stock · delivery 2-3 days

Product number: 124591.280.BL1

Product data

Manufacturer: Ajax
Article number: 124591.280.BL1
EAN / GTIN: 4823114068386

Description

This addressable dual input/output module links a fire alarm control panel with wired third-party automation systems and devices. Two input lines, Input 1 and Input 2, share a common Shield terminal and accept NO, NC, EOL, 2EOL and 3EOL connection types with 0.47 kΩ, 1.2 kΩ, 2.7 kΩ and 6.2 kΩ resistors, over wired runs of up to 325 ft using a cable cross-section of 0.4–2.5 mm² (21–13 AWG). The relay outputs Output 1 and Output 2 switch 10—250 V~ from 5 mA to 10 A or 10—30 V⎓ from 5 mA to 5 A, in both cases with a resistive load and the same cable cross-section. Input monitoring reports loss of the wired connection, short circuits and malfunctions whenever the EOL, 2EOL or 3EOL wiring is in use. The radio side relies on Jeweller with two-way communication, GFSK modulation, frequency hopping and up to 20 mW ERP with automatic power control, over a range of up to 5,550 ft. Device authentication prevents spoofing, connection loss is signalled after 36 s, and the module is powered by 2 × CR123A cells.

2 input lines, 2 relay outputs
NO, NC, EOL, 2EOL and 3EOL connection types
Outputs 10—250 V~ up to 10 A
Wired runs up to 325 ft
Jeweller radio up to 5,550 ft
Powered by 2 × CR123A

Made by

Ajax

Ajax Systems is the alarm and security system with the widest range in the catalogue: hubs, motion, opening and glass break detectors, MotionCam with photo verification, sirens, keypads, the EN54 fire detection line, cameras, the Ajax NVR and automation and comfort devices – as the Jeweller wireless system or wired via Fibra, in white and black. The Superior line is certified to EN 50131 Grade 3. AI4Vision is an authorised Ajax partner. All devices are managed through the Ajax app and the monitoring station connection; trade partners see prices and availability after login.

Notes

For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.

Specifications

Additional information (1)

Additional information – Warranty: 24 months

Anti-sabotage protection (1)

Anti-sabotage protection – Lost connection detection: after 36 s

Communication (7)

Communication – Encrypted communication: Alle gespeicherten und übertragenen Daten werden durch eine Blockverschlüsselung mit dynamischem Schlüssel geschützt.
Communication – Frequency bands: 866.0–866.5 MHz868.0–868.6 MHz868.7–869.2 MHz905.0–926.5 MHz915.85–926.5 MHz921.0–922.0 MHz
Communication – Frequency hopping: To prevent radio interference and jamming.
Communication – Jeweller communication technology: Two-way communication., Advanced sabotage protection., Block encryption featuring a dynamic key., Instant notifications., Remote control and configuration in Ajax apps., Proprietary wireless communication technology to transmit commands, alarms, and event
Communication – Maximum effective radiated power (ERP): up to 20 mW, Automatic power control to reduce power consumption and radio interference.
Communication – Radio communication range: up to 5,550 ft
Communication – Radio signal modulation: GFSK

Enclosure (6)

Enclosure – Dimensions: 4.57" × 7.09" × 2.44"
Enclosure – Flammability rating: UL 94 V-0
Enclosure – Operating humidity: up to 80%
Enclosure – Operating temperature range: from 32 °F to 122 °F
Enclosure – Protection class: IP21C
Enclosure – Weight: 19.3 oz

Inputs (6)

Inputs – Cross-sectional area of the cable: 0.4–2.5 mm² (21–13 AWG)
Inputs – EOL resistance: 0.47 kΩ, 1.2 kΩ, 2.7 kΩ, and 6.2 kΩ resistors
Inputs – Input terminals: Input 1, Input 2 — inputs for connecting third-party wired devices., Shield — common input for connecting shields of the cables that connect third-party wired devices.
Inputs – Length of wired connection to third-party devices: up to 325 ft
Inputs – Number of input lines for third-party devices: 2
Inputs – Type of connection: NO, NC, EOL, 2EOL, 3EOL

Outputs (5)

Outputs – AC operating range: 10—250 V~, 5 mA to 10 A (resistive load)
Outputs – Cross-sectional area of the cable: 0.4–2.5 mm² (21–13 AWG)
Outputs – DC operating range: 10—30 V⎓, 5 mA to 5 A (resistive load)
Outputs – Number of output lines for third-party devices: 2
Outputs – Output terminals: Output 1, Output 2 — relay outputs for connecting third-party wired devices.

Power supply (2)

Power supply – Battery: 2 × CR123A
Power supply – Calculated battery life: up to 5 years

Sabotage protection (2)

Sabotage protection – Input monitoring: detection of wired connection loss, short circuits, and malfunctions when the EOL, 2EOL, or 3EOL connection is used
Sabotage protection – Protection against spoofing: device authentication
