Ajax EN54 FireProtect (Heat/Sounder) white
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 2-3 days
Product data
- Manufacturer
- Ajax
- Article number
- 119915.274.WH1
- EAN / GTIN
- 4823114053801
Description
This wireless device raises both an audible and a visual alarm and reaches the system over Jeweller radio, which uses two-way communication, frequency hopping and block encryption with a dynamic key. The link runs at up to 5,550 ft with GFSK modulation and up to 20 mW ERP, and automatic power control limits both consumption and radio interference. Thirty-two sound patterns are available, among them tone 1 at 970 Hz from 71 dB and tone 2 at 800 Hz / 970 Hz @ 2 Hz from 76 dB, each reaching a maximum of 100 dB, while the light output cycles 90 ms ON and 1,910 ms OFF over 2,000 ms, or 0.5 Hz. Four CR123A cells give a calculated life of up to 5 years at 185 mA in alarm mode, with Huiderui CR123A, 3 V, 1,600 mAh LiMnO₂ as the recommended type. The enclosure measures 5.71 × 5.71 × 2.00 in, weighs 1.237 lb and works from 14 °F to 140 °F at up to 80% humidity. A SmartBracket lock holds the unit on its mounting panel, device authentication counters spoofing, and connection loss is reported after 36 s.
- Acoustic and light alarm type
- Jeweller radio up to 5,550 ft
- 32 tones, maximum 100 dB
- Flash frequency 0.5 Hz
- 4 × CR123A, up to 5 years battery life
- Enclosure 5.71 × 5.71 × 2.00 in, 1.237 lb
Made by
Ajax Systems is the alarm and security system with the widest range in the catalogue: hubs, motion, opening and glass break detectors, MotionCam with photo verification, sirens, keypads, the EN54 fire detection line, cameras, the Ajax NVR and automation and comfort devices – as the Jeweller wireless system or wired via Fibra, in white and black. The Superior line is certified to EN 50131 Grade 3. AI4Vision is an authorised Ajax partner. All devices are managed through the Ajax app and the monitoring station connection; trade partners see prices and availability after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Additional information (1)
- Additional information – Warranty
- 24 months
Alarm annunciation (5)
- Alarm annunciation – Alarm type
- acoustic and light
- Alarm annunciation – Current consumption in alarm mode
- 185 mA
- Alarm annunciation – Flash frequency
- 90 ms ON / 1,910 ms OFF (cycle duration: 2,000 ms; frequency: 0.5 Hz)
- Alarm annunciation – Sound pattern
- 32 tones
- Alarm annunciation – Sound volume
- Tone 1: 970 Hz — min 71, max 100 dB, Tone 2: 800 Hz / 970 Hz @ 2 Hz — min 76, max 100 dB, Tone 3: 800–970 Hz @ 1 Hz — min 76, max 96 dB, Tone 6: 554 Hz, 0.1 s / 440 Hz, 0.4 s — min 72, max 92 dB, Tone 7: 500–1200 Hz, 3.5 s / 0.5 s OFF — min 75, max 98 dB,
Communication (7)
- Communication – Encrypted communication
- Alle gespeicherten und übertragenen Daten werden durch eine Blockverschlüsselung mit dynamischem Schlüssel geschützt.
- Communication – Frequency bands
- 866.0 – 866.5 MHz, 868.0 – 868.6 MHz, 868.7 – 869.2 MHz, 905.0 – 926.5 MHz, 915.85 – 926.5 MHz, 921.0 – 922.0 MHz
- Communication – Frequency hopping
- To prevent radio interference and jamming.
- Communication – Jeweller communication technology
- Two-way communication., Advanced sabotage protection., Block encryption featuring a dynamic key., Instant notifications., Remote control and configuration in Ajax apps., Proprietary wireless communication technology to transmit commands, alarms, and event
- Communication – Maximum effective radiated power (ERP)
- up to 20 mW, Automatic power control to reduce power consumption and radio interference.
- Communication – Radio communication range
- up to 5,550 ft
- Communication – Radio signal modulation
- GFSK
Enclosure (6)
- Enclosure – Dimensions
- 5.71" × 5.71" × 2.00"
- Enclosure – Flammability rating
- UL 94 V-0
- Enclosure – Operating humidity
- up to 80%
- Enclosure – Operating temperature range
- from 14 °F to 140 °F
- Enclosure – Protection class
- IP54
- Enclosure – Weight
- 1.237 lb
Power supply (3)
- Power supply – Battery
- 4 × CR123A
- Power supply – Calculated battery life
- bis zu 5 Jahren
- Power supply – Recommended battery type
- Huiderui CR123A; 3 V; 1,600 mAh, LiMnO₂
Sabotage protection (3)
- Sabotage protection – Connection loss detection
- after 36 s
- Sabotage protection – Lock for SmartBracket
- to secure the device on the SmartBracket mounting panel
- Sabotage protection – Protection against spoofing
- device authentication
