55” 4K Digital Signage Display
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 3-4 days
Product data
- Manufacturer
- AG-Neovo
- Article number
- QM5503
Description
Measuring 55 inches, this digital signage display renders UHD 3840 x 2160 content in 16:9 and reaches 500~700 cd/㎡ with 178/178 viewing angles. Continuous 24/7 operation is supported and anti-burn-in is included. Sources connect through HDMI, USB Type-B and USB Type-C, while audio leaves the unit via two 10 W speakers or the 3.5 mm stereo jack output. External control runs over RJ45 and an RS232 input on a 3.5 mm phone jack. The black chassis with plastic rear cover measures 1238.4 x 709.2 x 70.0 mm without base and mounts in landscape or portrait. Batteries, an HDMI cable, power adaptor, quick start guide and remote control are supplied.
- UHD 3840 x 2160 (16:9)
- Brightness 500~700 cd/㎡
- 24/7 operation with anti-burn-in
- 10 W x 2 internal speakers
- HDMI, USB Type-B and USB Type-C inputs
- RJ45 and RS232 external control
Made by
AG Neovo builds displays for continuous operation: surveillance monitors with 24/7 rating, metal housing and burn-in protection from 10 to 55 inches, public view monitors with a built-in camera, stretched displays for video walls, 4K digital signage, interactive smartboards with AI camera, plus workstations and mounts. Every model comes with technical data, data sheet, manual and certificates. AI4Vision is an authorised distributor; trade prices after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
- Anti-Burn-in
- Yes
- Aspect Ratio
- 16:9
- Audio Out
- Stereo Audio Jack (3.5 mm)
- Bezel Width
- Even bezel 12.8 mm
- Brightness
- 500 cd/m², 500~700 cd/㎡
- Casing Colour
- Black
- Certifications & Compliance
- FCC, ICES-003 Issue 7, CE, LVD, WEEE, RoHS, REACH, UKCA
- Contrast Ratio
- 5000:1
- Display Colour
- 1.07G
- External Control
- RJ45, RS232
- Features
- 24-7, Casing Colour (Black & White), Speaker
- Frequency (H)
- 15-135 kHz
- Frequency (V)
- 24-85 Hz
- HDMI
- 2.0 x 2
- Humidity
- DTS-01
- Humidity
- 20%-80% (non-condensing)
- IK Rating
- LMK-01, LMK-03
- Innovation
- Anti-Burn-in Technology
- Inputs
- HDMI, USB Type-B, USB Type-C
- Internal Speakers
- 10W x 2
- Max. Resolution
- UHD 3840 x 2160
- On Mode
- 135W (On)
- Operating Time (Internal)
- 24/7
- Orientation
- Landscape / Portrait
- Outputs
- Audio
- Packaging
- 17.6 kg (38.8 lb)
- Packaging (W x H x D)
- 1390.0 x 830.0 x 144.0 mm (54.7" x 32.7" x 5.7")
- Panel Size
- 54.6"
- Panel Size on Carton
- 55.0"
- Panel Type
- VA
- Pixel Pitch
- 0.315 mm
- Product w/o Base
- 13 kg (28.7 lb)
- Product w/o Base (W x H x D)
- 1238.4 x 709.2 x 70.0 mm (48.8" x 27.9" x 2.8")
- RJ45
- RJ45 x 1
- RS232 In
- 3.5 mm Phone Jack
- Rear Cover Material
- Plastic
- Resolution
- UHD 3840 x 2160 (16:9)
- Response Time
- 5 ms
- Sizes
- 46"-55"
- Software
- Neovo Controller
- Standby Mode
- < 0.5W
- Supplied
- Batteries, HDMI Cable, Power Adaptor, Quick Start Guide, Remote Control
- Surface Treatment
- Anti-Glare Treatment (Haze 25%), 3H Hard Coating
- Temperature
- -20°C-60°C (-4°F-140°F), 0°C-40°C (32°F-104°F)
- Tilt
- CMP-01 + LMK-01
- Type-C
- x 1 (w/o PD)
- USB
- 2.0 x 1 (Service Port / Media Playback)
- VESA FPMPMI
- Yes (400 x 400 mm)
- Video Wall Mount
- VWM-01
- Viewing Angle (H/V)
- 178°/178°
- Viewing Angles
- 178/178
- Visibility
- Black-level Adjustment, Gamma Selection
- Wall Mount
- LMA-01, LMA-02
