4CH AI NVR
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 3-4 days
Product data
- Manufacturer
- Hanwha Vision
- Article number
- XRN-426S-2T
- EAN / GTIN
- 8801089241122
- Weight
- 1.73 kg
- Dimensions (W×H×D)
- 255 × 205 × 155 mm
Description
Equipped with a pre-installed 2TB SSD in an M.2 slot, the XRN-426S-2T is an AI-capable network video recorder for up to four cameras from CIF to 8MP. Cameras are integrated over SUNAPI and ONVIF, and recording is performed in H.265, H.264 and MJPEG at a maximum of 40Mbps. Four PoE ports at 10/100 supply the cameras, while the HDMI output presents 3840x2160 at 30Hz locally with dynamic layout, virtual channel view and up to four divisions. Playback runs at up to 32Mbps with a maximum of 16 simultaneous channels, and searching covers time, event, text, export, ARB and bookmarks. Combined with Hanwha AI cameras it adds AI search by object attribute, and backups are stored locally as recorder, SEC, AVI or JPG files and over the network as AVI or PNG.
- Up to 4 channels, 8MP cameras
- Pre-installed 2TB SSD in M.2 slot
- 4 PoE ports (LAN, 10/100)
- Max. 40Mbps recording bandwidth
- AI search by object attribute
- HDMI output at 3840x2160, 30Hz
Made by
Hanwha Vision (formerly Hanwha Techwin, the Wisenet brand) is the largest manufacturer in the AI4Vision catalogue: dome, bullet, PTZ, fisheye, multi-sensor and thermal cameras, network recorders, the Wisenet WAVE video management system, encoders and decoders, monitors, IP audio, intercom and access controllers, plus mounts and housings. The P and X series cameras carry AI video analytics on board. As an authorised distributor, AI4Vision carries the Wisenet range with technical data and manufacturer data sheets; trade partners see prices and availability after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Display (6)
- Decoding local display
- HDMI1: 3840x2160 (30Hz)
- Decoding resolution
- [Local Monitor] 8M(30fps), 1080p(4ch@30fps), 720P(4ch@30fps), D1(4ch@30fps)
- Multi-Screen-Display
- Dynamic layout, Virtual channel view, Up to 4 Div. [Web] 1/ 2H/ 2V/ 3V/ 4
- Network camera inputs
- Max. 4CH
- Network camera protocol
- SUNAPI, ONVIF
- Network camera resolution
- 8MP ~ CIF
Electrical (4)
- Electrical power consumption
- 54VDC/1.67A
- PoE-Budget
- 50W
- Power Consumption w/o PoE
- 18W
- Power consumption
- Max. 68W(PoE On)
Environment (2)
- Operating humidity
- 20% ~ 85% RH
- Operating temperature
- 0°C to +40°C(32℉ to 104℉)
Function (11)
- Camera setup items
- IP address, Add profile edit, Bitrate, Camera MD setup (4, 8 point polygon) Camera video setup (Simple focus, Brightness/Contrast, Flip/Mirror, IRIS, WDR, D&N, SSNR, Shutter, SSDR, DIS), Fisheye Dewarping Mode, Hallway View Setup, Camera Webpage
- Camera setup registration
- Auto, Manual
- Easy configuration
- P2P(QR code)
- Function Max. remote users
- Search(3), Live Unicast(10)
- PTZ control
- Via GUI, Webviewer
- PTZ preset
- 300 Presets
- Protocol support
- RTP, RTSP, HTTP, CGI(SUNAPI)
- Redundancy ARB
- Support
- Redundancy failover
- N+1
- Smartphone control
- Live: Multi-Profile Support, Multi Channel Playback
- Supported platforms
- iOS, Android
Intelligente Analyse (1)
- KI-Suche Objektattribut
- Compatible with Hanwha AI Cameras
Interface (7)
- Front panel indication
- Power, Record, Network
- Interface Alarm
- In 4EA, Out 2EA
- Interface Audio
- Out 1EA (RCA output)
- Interface Ethernet
- PoE RJ-45(LAN, 10/100) 4ea, RJ-45 1ea (WAN, 1Gbps)
- Interface HDMI
- 1EA 3840x2160(30Hz)
- Interface – USB
- 2EA(Front 2 x USB 2.0), Support for Wi-Fi dongle for Install
- Power input
- DC Adaptor
Mechanical (3)
- Colour / material
- Black / Metal & Plastic
- Dimensions
- 200.0 x 140.0 x 42.0 mm (7.87 x 5.51 x 1.65 inch)
- Weight
- 0.66Kg(1.45lb)
Network (11)
- Audio Audiokommunikation
- 2-Way
- Audio compression
- G.711, G.726, AAC(16/48KHz)
- Audio input/output
- 4CH (network)/output (Set)
- DDNS
- Hanwha DDNS
- Max. remote users
- Search(3), Live Unicast(10), Multicast(20)
- Network security
- IP address filtering, User access Log, 802.1x, TLS, Encryption Device certificate(Hanwha Techiwn Root CA), Signed firmware
- Network – Protocol
- IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S), SUNAPI(Server, Client)
- Supported browsers
- Google Chrome, Microsoft Edge, Mac Safari
- Supported operating system
- Windows10 or higher, macOS 13.5.2 or higher
- Transmission bandwidth
- Max. 80Mbps
- Viewer-Software
- WAVE, SSM, Webviewer, Wisenet Viewer, Wisenet mobile Support CGI(SUNAPI) for integration to 3'rd party VMS
Performance (17)
- Backup File backup
- Recorder/SEC/AVI/JPG(Local), AVI/PNG(Network)
- Backup Function
- Multi channel(Up to 4CH) Play, Date-Time/Title display
- Gleichzeitige Wiedergabe
- Max. 16CH(Local 4CH, Remote 4CH per user)
- Operating system Embedded
- Linux
- Playback bandwidth
- Max. 32Mbps
- Playback control
- Fast/Slow Forward / Backward, Move one step Up / Down
- Recording bandwidth
- Max. 40Mbps
- Recording compression
- H.265, H.264, MJPEG
- Recording event action
- e-Mail, Event Push, PTZ Preset, Alarm Out, Buzzer, Monitor Out, FTP, SUNAPI Command, Shutdown
- Recording event trigger
- Alarm Input, Video Loss, Camera Event(Sensor, MD, Video Analytics, Defocus, Audio), Dynamic Event, User Event
- Recording mode
- Normal, Dual Stream, Schedule(Continuous/Event), Event (Pre/Post), Bookmark
- Recording resolution
- 8MP ~ CIF
- Search & playback resolution
- CIF ~ 8MP
- Search & playback users
- Max. 4 Users (Local 1, Remote 3)
- Storage HDD slot (ea.)
- M.2 SSD 1EA
- Storage supported HDD
- Pre-installed 2TB SSD
- Suchen & abspielen Modus
- Time/Event/Text/Export/ARB/Bookmark
System (3)
- Protocol Protocol list
- Max. 100,000 (System Log, Event Log each)
- Sprache
- English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch, Swedish, Czech, Portuguese, Danish, Rumanian, Serbian, Croatian, Hungarian, Greek, Norwegian, Finnish, Korean, Chinese, Japanese, Thai, Vietnamese
- System control
- Mouse(include wireless), Keyboard(include wireless), Web
