37” Ultra-Wide Stretched Display
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 3-4 days
Product data
- Manufacturer
- AG-Neovo
- Article number
- PB3701
- EAN / GTIN
- 4710739598643
Description
The PB3701 is an ultra-wide stretched display with a 37.0 inch IPS panel, 1920 x 540 resolution and a 32:9 aspect ratio. Brightness is 500~700 cd/㎡ and response time 5ms, with the panel released for 24/7 use in landscape or portrait orientation. The surface carries an anti-glare treatment at 25% haze together with a 3H hard coating, and an anti-burn-in function is provided. Signals run through two DisplayPort 1.2 inputs and a DisplayPort output plus an IR input, with an IR sensor supplied; two 5 W speakers reproduce audio. The rear cover is metal, the casing is black and is also offered in black and white. On-mode consumption is 24W, humidity tolerance is 5%-95% non-condensing, and approvals cover CE, LVD, REACH, RoHS, UKCA and WEEE.
- 37.0 inch IPS panel, 1920 x 540 (32:9)
- 500~700 cd/㎡ brightness
- 24/7 operation, landscape or portrait
- 2x DisplayPort 1.2, DisplayPort output
- 5 W x 2 internal speakers
- Anti-burn-in, metal rear cover
Made by
AG Neovo builds displays for continuous operation: surveillance monitors with 24/7 rating, metal housing and burn-in protection from 10 to 55 inches, public view monitors with a built-in camera, stretched displays for video walls, 4K digital signage, interactive smartboards with AI camera, plus workstations and mounts. Every model comes with technical data, data sheet, manual and certificates. AI4Vision is an authorised distributor; trade prices after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
- Anti-Burn-in
- Yes
- Aspect Ratio
- 32:9
- Brightness
- 500~700 cd/㎡
- Casing Colour
- Black
- Certifications & Compliance
- CE, LVD, REACH, RoHS, UKCA, WEEE
- DisplayPort
- 1.2 x 2, x 1
- Features
- Casing Colour (Black & White)
- Frequency (H)
- 30-81kHz
- Frequency (V)
- 56-76Hz
- Humidity
- 5%-95% (non-condensing)
- IR In
- RJ45 x1
- IR Out
- RJ45 x1
- Inputs
- IR
- Internal Speakers
- 5 W x 2
- Max. Resolution
- 1920 x 540
- On Mode
- 24W (On)
- Operating Time (Internal)
- 24/7
- Orientation
- Landscape / Portrait
- Outputs
- DisplayPort
- Panel Size
- 37"
- Panel Size on Carton
- 37.0"
- Panel Type
- IPS
- Product w/o Base
- 7.2 kg (15.9 lb)
- Product w/o Base (W x H x D)
- 914.9 x 280.9 x 48.8 mm (36.0" × 11.1" × 1.9" )
- Rear Cover Material
- Metal
- Resolution
- 1920 x 540 (32:9)
- Response Time
- 5ms
- Software
- Neovo Controller
- Supplied
- IR Sensor
- Surface Treatment
- Anti-Glare Treatment (Haze 25%), 3H Hard Coating
