27" Monitor w/built-in IP Video Decoder
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 3-4 days
Product data
- Manufacturer
- Hanwha Vision
- Article number
- SMT-2721D
- EAN / GTIN
- 8801089236487
- Weight
- 8 kg
- Dimensions (W×H×D)
- 725 × 150 × 500 mm
Description
The SMT-2721D is a 27-inch Full HD monitor with a built-in video decoder that handles up to 64 live streams and cameras of up to 4K. Several screen layouts are selectable; HDMI 1 feeds the internal main monitor while HDMI 2 drives an external secondary display at 1280x720, 1280x1024 or 1920x1080, each at 60 Hz. The panel resolves 1920x1080 at 300 cd/m2 with a 3000:1 contrast ratio, 12 ms response time, 178-degree viewing angles and 30,000 hours of rated life. Connectivity covers one RJ-45 10/100/1000BASE-T port, two USB 2.0 ports for mouse and keyboard, a further USB 2.0 port for firmware upgrades and two 8 ohm 1 W speakers. Power is supplied either by DC24V or HPoE per 802.3bt at 31 W. Hanwha states FCC certification, NDAA compliance and manufacture in Korea, with operation from 0 to +40 C at 10 to 80 percent non-condensing humidity.
- 27 inch with integrated video decoder
- Up to 64 live video streams
- Camera support up to 4K
- HDMI output for an external monitor
- Dual power: DC24V or HPoE 802.3bt
- Gigabit Ethernet over RJ-45
Made by
Hanwha Vision (formerly Hanwha Techwin, the Wisenet brand) is the largest manufacturer in the AI4Vision catalogue: dome, bullet, PTZ, fisheye, multi-sensor and thermal cameras, network recorders, the Wisenet WAVE video management system, encoders and decoders, monitors, IP audio, intercom and access controllers, plus mounts and housings. The P and X series cameras carry AI video analytics on board. As an authorised distributor, AI4Vision carries the Wisenet range with technical data and manufacturer data sheets; trade partners see prices and availability after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Decoder (11)
- Decoder Audio Codec
- G.711 / G.726 / AAC
- Decoder Log
- Max. 100,000 (System log)
- Decoder Management
- Local UI, Web-Viewer, SSM
- Decoder Protocol
- RTP, RTSP, HTTP, CGI (SUNAPI), ONVIF
- Decoder Security
- IP address filtering, User access Log, 802.1x, Encryption, Device certificate(Hanwha Techwin Root CA), Signed firmware
- Decoder Video Codec
- H.265 / H.264 / MJPEG
- Export/Import
- Configuration Export/Import
- Max. Decoding Performance
- 2x8M@30fps, 12x2M@30fps
- Time Setting
- NTP/Manual
- Video Division (/Monitor)
- - Clone mode (HDMI#1) Max. 64, - Expand mode (HDMI#1) Max. 36 (HDMI#2) Max. 25
- Video Layout
- Up to 20, Sequence support
Display (10)
- Display Aspect Ratio
- 16:9
- Display Brightness
- 300 cd/m²
- Display Color
- 16.7M
- Display Contrast Ratio
- 3000:1
- Display Max. Resolution
- 1920x1080
- Display Response Time
- 12ms
- Display Screen Size
- 27inch
- Display Type
- LED Monitor
- Display Viewing Angle (H/V)
- 178°/178°
- Panel Life
- 30,000 hours
General (10)
- Dimensions without Stand
- 624x387x58mm(24.6x15.2x2.3")
- General / Electrical – Input Voltage
- DC24V, HPoE 802.3bt
- General / Electrical – Power Consumption
- 31W
- General / Environmental – Operating Humidity
- 10% ~ 80% (non-condensing)
- General / Environmental – Operating Temperature
- 0 ~ +40°C (+32°F ~ +104°F)
- General Mechanical Weight
- 6.5kg(14.3lb)
- Mechanical Cabinet Color
- Black
- Mechanical Packing Dimension
- 725x500x150mm(28.5x19.7x5.9")
- Mechanical Packing Weight
- 8.2kg(18.1lb)
- VESA Mounts Interface
- 100x100mm, 200x100mm, 200x200mm
Interface (6)
- Audio Output Signal
- Speakers : 8Ω 1W x 2
- HDMI Available Format
- 1280x720@60Hz, 1280 X 1024@60Hz, 1920x1080@60Hz
- HDMI Connector
- HDMI
- Interface USB
- 2xUSB 2.0(Mouse,Keyboard), 1xUSB 2.0 (AD Firmware upgrade)
- Network Ethernet
- 1xRJ-45 10/100/1000BASE-T
- Video Connectors
- HDMI#1 - Internal, Decoder main monitor, HDMI#2 - External, Decoder secondary monitor
On Screen Display (2)
- Functions
- VESA™ DPMS Compatible
- On Screen Display Language
- English, Spanish, French, Korean
