1-Port PoE PD EPoT RX Adapter
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 2-3 weeks
Product data
- Manufacturer
- AETEK
- Article number
- TE11-110-RX-V2
- EAN / GTIN
- 4711502643669
Description
Receive end of an EPoT link, sitting at the head of the run: one EPoT port on RJ45 and one 10/100 Mbps PoE PD port. Every watt for the link is drawn from a PoE switch or injector – IEEE 802.3bt at 90 W is the recommendation – and 30 W, 60 W or 48 to 56 VDC at the DC jack are accepted as well. Data and power travel over shielded Cat5e/6 STP/FTP cable on four pairs, two pairs or one pair for as far as 1,200 m, with data alone reaching 2,400 m at 100 Mbps. That feeds both the TX adapter and the camera at the far end with no switch or power supply in between. Peer-to-peer, daisy-chain and failover ring topologies work, and an eight-bay 19-inch chassis (CH-110-V2) is available as an option. The unit draws 2 W; surge protection is 6 kV, ESD ±4 kV contact and ±8 kV air. Metal case 102.9 x 48.9 x 27.0 mm, 0.2 kg, wall or optional DIN-rail mounting, operating range -20 °C to 60 °C, EN62368-1.
Made by
AETEK builds PoE switches for video security installations: from compact 4-port units to 24-port switches, with PoE+ and PoE++/bt, as desktop, rack and ceiling units with daisy-chain capability, also for outdoors with fibre uplinks. For selection, look at total PoE budget, port count, SFP uplinks and temperature range. Technical data and data sheets on every article, trade prices after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Certifications (3)
- Certifications EMC
- CE, FCC, VCCI, C-Tick
- Certifications MTBF
- > 50000 hours
- Safety
- EN62368-1
Environmental (3)
- Environmental – Operating Temperature
- -20°C ~ 60°C (-4°F ~ 140°F)
- Environmental – Storage Temperature
- -20°C ~ 85°C (-4°F ~ 185°F)
- Relative Humidity
- 5% ~ 95% non-condensing
Interface (5)
- Distance 10/100 Mbps Ethernet
- PoE PD RJ45 x1
- Distance Cable Type
- STP/FTP cat5e/6 shielded cable
- Distance EPoT Ports
- RJ45 x1
- Distance Transmission mode
- Receiver RX mode
- Interface / Distance – MAX.(Power+Data) Distance 100Mbps, 16W@1,200m(3,937ft) 100Mbps@2,400m(7,874ft) Data only Cable reference: Cat6 Bandwidth
- 100 Mbps
LEDs (4)
- LEDs LAN
- Ethernet status
- LEDs POE
- PoE status
- LINK/BNC
- EPoT RX and TX connection status
- PWR
- Power status
Mechanical (5)
- Dimensions (LxWxH)
- 102.9 x 48.9 x 27.0 mm (4.05 x 1.93 x 1.06 in)
- Mechanical Casing
- Metal
- Mechanical Connectors
- EPoT RJ45 x1, PoE PD LAN RJ45 x1, DC Jack x1
- Mechanical Mounting Type
- Wall mount, Din-rail (optional)
- Mechanical Weight
- 0.2 kg (0.44 lb)
Power (3)
- EPoT Surge Protection
- 6KV
- ESD
- Contact ±4 KV, Air ±8 KV
- Power – Input Power Support 30W/60W/90W PoE DC power jack: 56VDC Power supply Optional : Input: 100-240VAC Output: 65W@56VDC or 120W@56VDC Power Adapter 60W/90W PoE Injector 60W/90W PoE Switch Unit Power Consumption
- 2 watts
