1-Port PoE PD EPoC RX Adapter
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 2-3 weeks
Product data
- Manufacturer
- AETEK
- Article number
- XE11-110-RX-V2
- EAN / GTIN
- 4711502643348
Description
EPoC receive adapter carrying one 75 Ω BNC port and one 10/100 Mbps PoE PD port, placed at the head end of a coaxial run. All power for the link is sourced from a PoE switch or injector: it accepts IEEE 802.3bt at 90 W, 802.3at at 30 W and 802.3af at 15.4 W as end-span or mid-span, or 48 to 56 VDC, and the manufacturer recommends 802.3bt with 90 W for long runs. Over RG59, RG6 or RG11 it passes data and PoE to the TX adapter and the camera as far as 1,200 m at 100 Mbps, with data alone reaching 2,400 m, so older CCTV cabling can move to IP without new cable. The unit draws 2 W. An eight-bay 19-inch chassis (CH-110-V2) and the SD-301 surge protector are optional. Metal case 103.4 x 48.9 x 27 mm, 0.2 kg, wall or optional DIN-rail mounting, operating range -20 °C to 60 °C, EN62368-1.
Made by
AETEK builds PoE switches for video security installations: from compact 4-port units to 24-port switches, with PoE+ and PoE++/bt, as desktop, rack and ceiling units with daisy-chain capability, also for outdoors with fibre uplinks. For selection, look at total PoE budget, port count, SFP uplinks and temperature range. Technical data and data sheets on every article, trade prices after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Certifications (2)
- Certifications EMC
- CE, FCC, VCCI, C-Tick
- Safety
- EN62368-1
Environmental (3)
- Environmental – Operating Humidity
- 5% ~ 95% non-condensing
- Environmental – Operating Temperature
- -20°C ~ 60°C (-4°F ~ 140°F)
- Environmental – Storage Temperature
- -20°C ~ 85°C (-4°F ~ 185°F)
Interface (4)
- Distance 10/100 Mbps Ethernet
- PoE PD RJ45 x1
- Distance EPoC Ports
- 75 ohm x1
- Distance Transmission mode
- Receiver RX mode
- Interface / Distance – MAX.(Power+Data) Distance 100Mbps, 9.7W@1,200m(3,937ft) 100Mbps@2,400m(7,874ft) Data only Cable reference: RG6 Coax Cable Type
- 75 ohm RG59/RG6/RG11 Coax
LEDs (5)
- DATA
- Data transmission status over coax
- LEDs LAN
- Ethernet status
- LEDs POE
- PoE status
- LINK
- EPoC RX and TX connection status
- PWR
- Power status
Mechanical (5)
- Dimensions (W x D x H)
- 103.4 x 48.9 x 27 mm (4.07 x 1.93 x 1.06")
- Mechanical Casing
- Metal
- Mechanical Connectors
- BNC x1, RJ45 x1, DC Jack x1
- Mechanical Mounting Type
- Wall mount, Din-rail (optional)
- Mechanical Weight
- 0.2 kg (0.44 lb)
Power (4)
- EPoC Surge Protection
- Optional extra surge protector : SD-301
- PoE Pass Through
- Support
- Power – Power Input IEEE 802.3bt PoE++ standard 90W PD IEEE 802.3at PoE+ end-span/mid-span 30W PD IEEE 802.3af PoE end-span/mid-span 15.4W PD PoE Output
- PoE over Coax
- Unit Power Consumption
- 2W
