1-Port PoE PD EPo2 RX Adapter
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 2-3 weeks
Product data
- Manufacturer
- AETEK
- Article number
- 2E11-110-RX-V2
- EAN / GTIN
- 4711502643379
Description
The 2E11-110-RX-V2 is the receiving half of an EPo2 pair: it takes data and power off the two-wire run and presents them at a 10/100 Mbit/s RJ45 port as a powered device. It can be fed from the two-wire line itself or from 48 to 56 V DC, and passes PoE through to the connected device. IP equipment can therefore reach the network where only old two-conductor wiring exists. No configuration is required and the unit itself draws 2 W.
Made by
AETEK builds PoE switches for video security installations: from compact 4-port units to 24-port switches, with PoE+ and PoE++/bt, as desktop, rack and ceiling units with daisy-chain capability, also for outdoors with fibre uplinks. For selection, look at total PoE budget, port count, SFP uplinks and temperature range. Technical data and data sheets on every article, trade prices after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Certifications (2)
- Certifications EMC
- CE, FCC, VCCI, C-Tick
- Safety
- EN62368-1
Environmental (3)
- Environmental – Operating Humidity
- 5% ~ 95% non-condensing
- Environmental – Operating Temperature
- -20°C ~ 60°C (-4°F ~ 140°F)
- Environmental – Storage Temperature
- -20°C ~ 85°C (-4°F ~ 185°F)
Interface (3)
- Distance 10/100 Mbps Ethernet
- PoE PD RJ45 x1
- Distance EPo2 Ports
- 2-Pin Terminal Block x1
- Distance Transmission mode
- Receiver RX mode
LEDs (5)
- DATA
- Data transmission status over 2 wires cable
- LEDs LAN
- Ethernet status
- LEDs POE
- PoE status
- LINK
- EPo2 RX and TX connection status
- PWR
- Power status
Mechanical (5)
- Dimensions (W x D x H)
- 102.9 x 48.9 x 27 mm (4.05 x 1.92 x 1.06")
- Mechanical Casing
- Metal
- Mechanical Connectors
- 2P Terminal Block x1, RJ45 x1, DC Jack x1
- Mechanical Mounting Type
- Wall mount, Din-rail (optional)
- Mechanical Weight
- 0.2 kg (0.44 lb)
Power (3)
- PoE Pass Through
- Support
- Power – Power Input IEEE 802.3bt PoE++ standard 90W PD IEEE 802.3at PoE+ end-span/mid-span 30W PD IEEE 802.3af PoE end-span/mid-span 15.4W PD DC power jack: 56VDC PoE Output
- PoE over 2 wires shielded cable
- Unit Power Consumption
- 2W
