1-Port EPoC TX Adapter with 802.3af/at/bt PoE++ Output
Price after sign-in
Prices and conditions are shown once you sign in with your customer account.
Sign inNot in stock · delivery 2-3 weeks
Product data
- Manufacturer
- AETEK
- Article number
- XE10-110-TX-V2
- EAN / GTIN
- 4711502643331
Description
EPoC transmit adapter with one 75 Ω BNC port and one RJ45 PoE output that feeds as PSE under IEEE 802.3af, 802.3at and 802.3bt. It sits at the camera end of a coaxial run and powers the camera with no local supply: over RG59, RG6 or RG11 the link is rated for 9.7 W at 1,200 m with 100 Mbps, a PoE IP camera is given up to 8.3 W, and data alone travels 2,400 m. Existing coax can therefore keep serving PoE IP cameras. Power arrives either as PoE on the coax or as 56 VDC at the DC jack; the unit draws 2 W and a DIP switch turns the PoE output off. An SD-301 surge protector is available as an option. Metal case 86.6 x 47.1 x 27.0 mm, 0.2 kg, wall or optional DIN-rail mounting, operating range -20 °C to 60 °C, humidity 5 to 95 % non-condensing, EN62368-1.
Made by
AETEK builds PoE switches for video security installations: from compact 4-port units to 24-port switches, with PoE+ and PoE++/bt, as desktop, rack and ceiling units with daisy-chain capability, also for outdoors with fibre uplinks. For selection, look at total PoE budget, port count, SFP uplinks and temperature range. Technical data and data sheets on every article, trade prices after login.
Notes
For technical specifications and product characteristics, only the details in the manufacturer's current product datasheet are authoritative. Illustrations may differ from the scope of delivery.
Specifications
Certifications (2)
- Certifications EMC
- CE, FCC, VCCI, C-Tick
- Safety
- EN62368-1
Environmental (3)
- Environmental – Operating Humidity
- 5% ~ 95% non-condensing
- Environmental – Operating Temperature
- -20°C ~ 60°C (-4°F ~ 140°F)
- Environmental – Storage Temperature
- -20°C ~ 85°C (-4°F ~ 185°F)
Interface (4)
- Distance 10/100 Mbps Ethernet
- PoE PSE RJ45 x1
- Distance Coaxial BNC
- 75 ohm x1
- Distance Transmission mode
- Transmitter TX mode
- Interface / Distance – MAX.(Power+Data) Distance 100Mbps, 9.7W@1,200m(3,937ft) 100Mbps@2,400m(7,874ft) Data only Cable reference: RG6 Coax Cable Type
- 75 ohm RG59/RG6/RG11 Coax
LEDs (5)
- DATA
- Data transmission status over coax
- LEDs LAN
- Ethernet status
- LEDs POE
- PoE status
- LINK
- EPoC RX and TX connection status
- PWR
- Power status
Mechanical (6)
- DIP Switch
- PoE On/Off switch
- Dimensions (W x D x H)
- 86.6 x 47.1 x 27.0 mm (3.41x1.85x1.06")
- Mechanical Casing
- Metal
- Mechanical Connectors
- BNC x1, RJ45 x1, DC Jack x1, PoE On/Off Switch x1
- Mechanical Mounting Type
- Wall mount, Din-rail (optional)
- Mechanical Weight
- 0.2 kg (0.44 lb)
Power (2)
- EPoC Surge Protection
- Optional extra surge protector : SD-301
- Power – Power Input PoE over Coax DC power jack: 56VDC Power Output IEEE 802.3bt PoE++ PSE IEEE 802.3at PoE+ PSE IEEE 802.3af PoE PSE Unit Power Consumption
- 2W
